Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 155
Accessories and Dimensions Appendix B
5.0 4.0 5.0 4.0 10.5 323...528 B 25-PM2-D010
7.5 5.5 7.5 5.5 13.0 323...528 C 25-PM2-D013
10.0 7.5 10.0 7.5 17.0 323...528 C 25-PM2-D017
15.0 11.0 15.0 11.0 24.0 323...528 D 25-PM2-D024
20.0 15.0 15.0 11.0 30.0 323...528 D 25-PM2-D030
25.0 18.5 20.0 15.0 37.0 323...528 E 25-PM2-D037
30.0 22.0 25.0 18.5 43.0 323...528 E 25-PM2-D043
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
0.5 0.4 0.5 0.4 0.9 446...660 A 25-PM1-E0P9
1.0 0.75 1.0 0.75 1.7 446...660 A 25-PM1-E1P7
2.0 1.5 2.0 1.5 3.0 446...660 A 25-PM1-E3P0
3.0 2.2 3.0 2.2 4.2 446...660 A 25-PM1-E4P2
5.0 3.7 5.0 3.7 6.6 446...660 B 25-PM1-E6P6
7.5 5.5 7.5 5.5 9.9 446...660 C 25-PM1-E9P9
10.0 7.5 10.0 7.5 12.0 446...660 C 25-PM1-E012
15.0 11.0 15.0 11.0 19.0 446...660 D 25-PM1-E019
20.0 15.0 15.0 11.0 22.0 446...660 D 25-PM1-E022
25.0 18.5 20.0 15.0 27.0 446...660 E 25-PM1-E027
30.0 22.0 25.0 18.5 32.0 446...660 E 25-PM1-E032
PowerFlex 520-Series Control Module
Item Description
Frame
Size Catalog No.
PowerFlex 525 Control
Module
Replacement control module for use with
PowerFlex 520-Series drives. Includes:
• Control Module
• Control Module Front Cover
A...E 25B-CTM1
Other Parts
Item Description
Frame
Size Catalog No.
PowerFlex 525 Control
Module Front Cover
Replacement cover for the control module I/O terminals,
EtherNet/IP and DSI ports.
A...E 25B-CTMFC1
PowerFlex 520-Series
Power Module Front Cover
Replacement cover for the PowerFlex 520-Series power
module.
B 25-PMFC-FB
C 25-PMFC-FC
D 25-PMFC-FD
E 25-PMFC-FE
PowerFlex 520-Series
Power Terminal Guard
Replacement finger guard for power terminals. A 25-PTG1-FA
B 25-PTG1-FB
C 25-PTG1-FC
D 25-PTG1-FD
E 25-PTG1-FE
PowerFlex 520-Series
Heatsink Fan Kit
Replacement fan for drive power module. A 25-FAN1-FA
B 25-FAN1-FB
C 25-FAN1-FC
D 25-FAN1-FD
E 25-FAN1-FE
Output Ratings
Input
Voltage Range
Frame
Size Catalog No.
Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
