Rockwell Automation Publication 520-UM001A-EN-E - February 2013 19
Installation/Wiring Chapter 1
100...120V 1-Phase Input Protection Devices – Frames A...B
200...240V 1-Phase Input Protection Devices – Frames A...B
200...240V 3-Phase Input Protection Devices – Frames A...E
(1) Normal and Heavy duty ratings are available for drives above 15 HP / 11 kW.
Catalog No.
Output Ratings Input Ratings
Frame
Size
Contactor
Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA Amps
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. UL 489 (140U) UL 140 (140M)
25B-V2P5N104 0.5 0.4 0.5 0.4 2.5 1.3 9.6 A 100-C12 15 20 140U-D6D2-C12 140M-C2E-C10 CLASS RK5, J or T / DLS-R-20 140U-D6C2-C12 140M-C2E-C10
25B-V4P8N104 1.0 0.75 1.0 0.75 4.8 2.5 19.2 B 100-C23 25 40 140U-D6D2-C25 140M-D8E-C20 CLASS RK5, J or T / DLS-R-40 140U-D6D2-C25 140M-D8E-C20
25B-V6P0N104 1.5 1.1 1.5 1.1 6.0 3.2 24.0 B 100-C23 30 50 140U-D6D2-C30 140M-F8E-C25 CLASS RK5, J or T / DLS-R-50 140U-D6D2-C30 140M-F8E-C25
Catalog No.
Output Ratings Input Ratings
Frame
Size
Contactor
Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA Amps
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. UL 489 (140U) UL 140 (140M)
25B-A2P5N104 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 15 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, J or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10
25B-A2P5N114 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 15 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, J or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10
25B-A4P8N104 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 15 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, J or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16
25B-A4P8N114 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 15 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, J or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16
25B-A8P0N104 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS J or T / 40 140U-D6D2-C25 140M-F8E-C25
25B-A8P0N114 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS J or T / 40 140U-D6D2-C25 140M-F8E-C25
25B-A011N104 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 30 50 140U-H6C2-C35 140M-F8E-C25 CLASS J or T / 50 140U-H6C2-C35 140M-F8E-C25
25B-A011N114 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 30 50 140U-H6C2-C35 140M-F8E-C25 CLASS J or T / 50 140U-H6C2-C35 140M-F8E-C25
Catalog No.
(1)
Output Ratings Input Ratings
Frame
Size
Contactor
Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA Amps
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. UL 489 (140U) UL 140 (140M)
25B-B2P5N104 0.5 0.4 0.5 0.4 2.5 1.2 2.7 A 100-C07 6 6 140U-D6D3-B40 140M-C2E-B40 CLASS RK5, J or T / DLS-R-6 140U-D6D3-B40 140M-C2E-B40
25B-B5P0N104 1.0 0.75 1.0 0.75 5.0 2.7 5.8 A 100-C09 10 15 140U-D6D3-B80 140M-C2E-B63 CLASS RK5, J or T / DLS-R-15 140U-D6D3-B80 140M-C2E-B63
25B-B8P0N104 2.0 1.5 2.0 1.5 8.0 4.3 9.5 A 100-C12 15 20 140U-D6D3-C10 140M-C2E-C10 CLASS RK5, J or T / DLS-R-20 140U-D6D3-C10 140M-C2E-C10
25B-B011N104 3.0 2.2 3.0 2.2 11.0 6.3 13.8 A 100-C23 20 30 140U-D6D3-C15 140M-C2E-C16 CLASS RK5, J or T / DLS-R-30 140U-D6D3-C15 140M-C2E-C16
25B-B017N104 5.0 3.7 5.0 3.7 17.5 9.6 21.1 B 100-C23 30 45 140U-D6D3-C25 140M-F8E-C25 CLASS J or T / 45 140U-D6D3-C25 140M-F8E-C25
25B-B024N104 7.5 5.5 7.5 5.5 24.0 12.2 26.6 C 100-C37 35 60 140U-H6C3-C35 140M-F8E-C32 CLASS J or T / 60 140U-H6C3-C35 140M-F8E-C32
25B-B032N104 10.0 7.5 10.0 7.5 32.2 15.9 34.8 D 100-C43 45 70 140U-H6C3-C60 140M-F8E-C45 CLASS RK5, J or T / DLS-R-70 – 140M-F8E-C45
25B-B048N104 15.0 11.0 15.0 11.0 48.3 20.1 44.0 E 100-C60 60 90 140U-H6C3-C70 140M-F8E-C45 CLASS J or T / 90 – –
25B-B062N104 20.0 15.0 15.0 11.0 62.1 25.6 56.0 E 100-C72 70 125 140U-H6C3-C90 140M-H8P-C70 CLASS J or T / 125 – –
