Rockwell Automation Publication 520-UM001A-EN-E - February 2013 21
Installation/Wiring Chapter 1
525...600V 3-Phase Input Protection Devices – Frames A...E
(1) Normal and Heavy duty ratings are available for drives above 15 HP / 11 kW.
Catalog No.
(1)
Output Ratings Input Ratings
Frame
Size
Contactor
Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA Amps
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. UL 489 (140U) UL 140 (140M)
25B-E0P9N104 0.5 0.4 0.5 0.4 0.9 1.4 1.2 A 100-C09 3 6 140U-D6D3-B20 140M-C2E-B25 CLASS RK5, J or T / DLS-R-6 – 140M-C2E-B25
25B-E1P7N104 1.0 0.75 1.0 0.75 1.7 2.6 2.3 A 100-C09 3 6 140U-D6D3-B30 140M-C2E-B25 CLASS RK5, J or T / DLS-R-6 – 140M-C2E-B25
25B-E3P0N104 2.0 1.5 2.0 1.5 3.0 4.3 3.8 A 100-C09 6 10 140U-D6D3-B50 140M-C2E-B40 CLASS RK5, J or T / DLS-R-10 – 140M-C2E-B40
25B-E4P2N104 3.0 2.2 3.0 2.2 4.2 6.1 5.3 A 100-C09 10 15 140U-D6D3-B80 140M-C2E-B63 CLASS RK5, J or T / DLS-R-15 – 140M-C2E-B63
25B-E6P6N104 5.0 3.7 5.0 3.7 6.6 9.1 8.0 B 100-C09 10 20 140U-D6D3-C10 140M-C2E-C10 CLASS RK5, J or T / DLS-R-20 – 140M-C2E-C10
25B-E9P9N104 7.5 5.5 7.5 5.5 9.9 12.8 11.2 C 100-C16 15 25 140U-D6D3-C15 140M-C2E-C16 CLASS RK5, J or T / DLS-R-25 – 140M-C2E-C16
25B-E012N104 10.0 7.5 10.0 7.5 12.0 15.4 13.5 C 100-C23 20 30 140U-D6D3-C20 140M-C2E-C16 CLASS RK5, J or T / DLS-R-30 – 140M-C2E-C16
25B-E019N104 15.0 11.0 15.0 11.0 19.0 27.4 24.0 D 100-C30 30 50 140U-H6C3-C30 140M-F8E-C25 CLASS J or T / 50 – –
25B-E022N104 20.0 15.0 15.0 11.0 22.0 31.2 27.3 D 100-C30 35 60 140U-H6C3-C35 140M-F8E-C32 CLASS J or T / 60 – –
25B-E027N104 25.0 18.5 20.0 15.0 27.0 28.2 24.7 E 100-C30 35 50 140U-H6C3-C35 140M-F8E-C32 CLASS J or T / 50 – 140M-F8E-C32
25B-E032N104 30.0 22.0 25.0 18.5 32.0 33.4 29.2 E 100-C37 40 60 140U-H6C3-C50 140M-F8E-C32 CLASS J or T / 60 – 140M-F8E-C32
