Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 77
Programming and Parameters Chapter 3
Terminal Block Group (continued)
t070 [Opto Out1 Level] Related Parameter(s): t069, t072
t073 [Opto Out2 Level]
32 bit parameter.
Determines the on/off point for the digital outputs when t069 or t072 [Opto Outx Sel] is set to the values shown below.
Values Default: 0
Min/Max: 0/9999
Display: 1
32
Min/Max Value Range Based On [Opto Outx Sel] Setting
6: 0...500 Hz 10: 0...100% 18: 0...180°
7: 0...180% 16: 0.1...9999 s 20: 0/1
8: 0...815V 17: 1...9999 counts 26: 0...150%
t075 [Opto Out Logic]
Determines the logic (Normally Open/NO or Normally Closed/NC) of the digital outputs only.
Values Default: 0
Min/Max: 0/3
Display: 1
Setting Digital Out 1 Logic Digital Out 2 Logic
0NO NO
1NC NO
2NO NC
3NC NC

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
