Allen-Bradley PowerFlex 70 Installation Instructions

32 Rockwell Automation Publication 20A-IN009E-EN-P - January 2015
PowerFlex 70 Adjustable Frequency AC Drive
Jumper Settings and Locations
Frame Voltage Code
Factory Default Jumper Settings
Power Source TypeMOV/Input Filter Caps
DC Bus Common Mode
Caps
A B
C
D
E
JP2/JP3
Installed
Not applicable Solid ground
Verify that the jumper at “JP2/JP3” is installed.
Non-solid ground
Remove the jumper at “JP2/JP3.”
B B
D
E
JP2/JP3
Installed
JP5/JP6
Installed
Important: The internal EMC filter (input filter) is a
factory-installed option on frame B drives. If the option
is installed, the drive cannot be used on a non-solid
ground power source.
To verify: an extra “R, S, T” terminal block is present if
the option is installed (as shown). Additionally, the 13th
character of the nameplate catalog number is “A” (see
page 31
).
Solid ground
Verify that the jumpers at both locations are installed
(JP2/JP3 and JP5/JP6).
Non-solid ground
Remove the jumpers at “JP2/JP3” and “JP5/JP6.” In
addition, verify that the input filter option is not
installed.
C JP2/JP3
Installed
JP5/JP6
Installed
JP3
JP2
MOV
JP3
JP2
JP5
JP6
MOV
CM Cap
L1
R
L2
S
L3
T
BR1
+DC
L1
R
L2
S
L3
T
Input Filter
Option
JP6 JP5
JP3
JP2
MOV
CM Cap
L1
R
L2
S
L3
T
BR1
+DC
L1
R
L2
S
L3
T
Input Filter
Option
or
