Allen-Bradley PowerFlex 70 Installation Instructions

Rockwell Automation Publication 20A-IN009E-EN-P - January 2015 33
PowerFlex 70 Adjustable Frequency AC Drive
C B
D
E
JP2/JP3
Installed
JP3A/JP3B
Installed
Solid ground
Verify that the jumpers at both locations (JP2/JP3 and
JP3A/JP3B) are installed.
Non-solid ground
Remove the jumpers at “JP2/JP3” and “JP3A/JP3B”.
C JP2/JP3
Installed
JP3A/JP3B
Installed
D B
D
E
JP2/JP3
Installed
JP3A/JP3B
Installed
Solid ground
Verify that the jumpers at both locations (JP2/JP3 and
JP3A/JP3B) are installed.
Non-solid ground
Remove the jumpers at “JP2/JP3” and “JP3A/JP3B”.
C JP2/JP3
Installed
JP3A/JP3B
Installed
Frame Voltage Code
Factory Default Jumper Settings
Power Source TypeMOV/Input Filter Caps
DC Bus Common Mode
Caps
JP3 JP2
JP3A
JP3B
MOV / Filter Cap
CM Cap
JP3
JP2
JP3A
JP3B
MOV / Filter Cap
CM Cap
SHLD
