Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 47
Programming and Parameters Chapter 1
DYNAMIC CONTROL (file D)
Restart Modes
178 [Sleep Wake Mode]
Enables/disables the Sleep/Wake function.
Important: When enabled, the following
conditions must be met:
· A proper value must be programmed for [Sleep
Level] and [Wake Level].
· A speed reference must be selected in [Speed Ref
A Sel].
· At least one of the following must be
programmed (and input closed) in [Digital Inx
Sel]; “Enable,” “Stop=CF,” “Run,” “Run Forward,
“Run Reverse.
Default:
Options:
0
0
1
2
“Disabled”
“Disabled”
“Direct” (Enabled)
“Invert” (Enabled)
(7)
179
183
(1)
When power is cycled, if all of the above conditions are present after power is restored, a restart
occurs.
(2)
If all of the above conditions are present when [Sleep-Wake Mode] is “enabled,” the drive starts.
(3)
The active speed reference is determined as explained in Speed Reference Control on page 116.
The Sleep/Wake function and the speed reference can be assigned to the same input.
(4)
Command must be issued from HIM, TB or network.
(5)
Run Command must be cycled.
(6)
Signal does not need to be greater than wake level.
(7)
Enhanced firmware revision 2.001 and later. For Invert function, refer to [Analog In x Loss].
File D
Group
No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
E C v2
ATTENTION: Enabling the Sleep-Wake function can cause unexpected
machine operation during the Wake mode. Equipment damage and/or
personal injury can result if this parameter is used in an inappropriate
application. Do Not use this function without considering the
information below and in Appendix C. In addition, all applicable local,
national and international codes, standards, regulations or industry
guidelines must be considered.
!
Conditions Required to Start Drive
(1)(2)(3)
Input After Powerup After a Drive Fault After a Stop
Command
Reset by Stop-CF,
HIM or TB
Reset by
Clear Faults
(TB)
HIM or TB
Stop Stop Closed
Wake Signal
Stop Closed
Wake Signal
New Start or Run
Cmd.
(4)
Stop Closed
Wake Signal
Stop Closed
Direct Mode
Analog Sig. > Sleep
Level
(6)
Invert Mode
Analog Sig. < Sleep
Level
(6)
New Start or Run
Cmd.
(4)
