A-8 Supplemental Drive Information
Table A.A 208 Volt AC Input Protection Devices (See page A-13 for Notes)
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
208 Volt AC Input
20BB2P2 0 0.5 0.33 4 50 1.9 0.7 2.5 2.8 3.8 3 6 3 10 15 3 M-C2E-B25 M-D8E-B25 – –
20BB4P2 0 1 0.75 4 50 3.7 1.3 4.8 5.6 7.0 6 10 6 17.5 15 7 M-C2E-B63 M-D8E-B63 – –
20BB6P8 1 2 1.5 4 50 6.8 2.4 7.8 10.4 13.8 10 15 10 30 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BB9P6 1 3 2 4 50 9.5 3.4 11 12.1 17 12 20 12 40 40 15 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BB015 1 5 3 4 50 15.7 5.7 17.5 19.3 26.3 20 35 20 70 70 30 M-C2E-C20 M-D8E-C20 M-F8E-C20 –
20BB022 1 7.5 5 4 50 23.0 8.3 25.3 27.8 38 30 50 30 100 100 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BB028 2 10 7.5 4 50 29.6 10.7 32.2 38 50.6 40 70 40 125 125 50 – – M-F8E-C32 -CMN-4000
20BB042 3 15 10 4 50 44.5 16.0 48.3 53.1 72.5 60 100 60 175 175 70 – – M-F8E-C45 -CMN-6300
20BB052 3 20 15 4 50 51.5 17.1 56 64 86 80 125 80 200 200 100 – – – -CMN-6300
20BB070425204507225.978.2931249017590300300100–––-CMN-9000
20BB080 4 30 25 4 50 84.7 30.5 92 117 156 110 200 110 350 350 150 – – – -CMN-9000
20BB104540–45011340.7120 132175150250150475350150––––
–3045084.730.592 138175125200125350300150–––-CMN-9000
20BB130 5 50 – 4 50 122 44.1 130 143 175 175 275 175 500 375 250 – – – –
– 40 4 50 98 35.3 104 156 175 125 225 125 400 300 150 – – – –
20BB154660–45016760.1177195266225350225500500250––––
–5045014150.9150225300200300200500450250––––
20BB192 6 75 – 4 50 208 75.0 221 243 308 300 450 300 600 600 400 – – – –
– 60 4 50 167 60.1 177 266 308 225 350 225 500 500 250 – – – –
