Supplemental Drive Information A-11
Table A.D 480 Volt AC Input Protection Devices (See page A-13 for Notes)
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
480 Volt AC Input
20BD1P1 0 0.5 0.33 4 50 0.9 0.7 1.1 1.2 1.6 3 3 3 6 15 3 M-C2E-B16 – – –
20BD2P1 0 1 0.75 4 50 1.6 1.4 2.1 2.4 3.2 3 6 3 8 15 3 M-C2E-B25 – – –
20BD3P4 0 2 1.5 4 50 2.6 2.2 3.4 4.5 6.0 4 8 4 12 15 7 M-C2E-B40 M-D8E-B40 – –
20BD5P0 0 3 2 4 50 3.9 3.2 5.0 5.5 7.5 6 10 6 20 20 7 M-C2E-B63 M-D8E-B63 – –
20BD8P0 0 5 3 4 50 6.9 5.7 8.0 8.8 12 10 15 10 30 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BD011 0 7.5 5 4 50 9.5 7.9 11 12.1 16.5 15 20 15 40 40 15 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BD014 1 10 7.5 4 50 12.5 10.4 14 16.5 22 17.5 30 17.5 50 50 20 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BD022 1 15 10 4 50 19.9 16.6 22 24.2 33 25 50 25 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BD027 2 20 15 4 50 24.8 20.6 27 33 44 35 60 35 100 100 50 – – M-F8E-C32 -CMN-4000
20BD034 2 25 20 4 50 31.2 25.9 34 40.5 54 40 70 40 125 125 50 – – M-F8E-C45 -CMN-4000
20BD040 3 30 25 4 50 36.7 30.5 40 51 68 50 90 50 150 150 50 – – M-F8E-C45 -CMN-4000
20BD052 3 40 30 4 50 47.7 39.7 52 60 80 60 110 60 200 200 70 – – – -CMN-6300
20BD065 3 50 40 4 50 59.6 49.6 65 78 104 80 125 80 250 250 100 – – – -CMN-9000
20BD077 4 60 – 4 50 72.3 60.1 77 85 116 100 170 100 300 300 100 – – – -CMN-9000
– 50 4 50 59.6 49.6 65 98 130 80 125 80 250 250 100 – – – -CMN-9000
20BD096 5 75 – 4 50 90.1 74.9 96 106 144 125 200 125 350 350 125 – – – –
– 60 4 50 72.3 60.1 77 116 154 100 170 100 300 300 100 – – – -CMN-9000
20BD125 5 100 – 4 50 117 97.6 125 138 163 150 250 150 500 375 150 – – – –
– 75 4 50 90.1 74.9 96 144 168 125 200 125 350 350 125 – – – –
20BD156 6 125 – 4 50 147 122 156 172 234 200 350 200 600 450 250 – – – –
– 100 4 50 131 109 125 188 250 175 250 175 500 375 250 – – – –
20BD180 6 150 – 4 50 169 141 180 198 270 225 400 225 600 500 250 – – – –
– 125 4 50 147 122 156 234 312 200 350 200 600 450 250 – – – –
20BD248 6 200 – 2 40 233 194 248 273 372 300 550 300 700 700 400 – – – –
– 150 2 50 169 141 180 270 360 225 400 225 600 500 250 – – – –
