Allen-Bradley powerflex 700 User Manual

A-12 Supplemental Drive Information
Table A.E 600 Volt AC Input Protection Devices (See page A-13 for Notes)
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
600 Volt AC Input
20BE1P7 0 1 0.5 4 50 1.3 1.4 1.7 2 2.6 2 4 2 6 15 3 M-C2E-B16 – – –
20BE2P7 0 2 1 4 50 2.1 2.1 2.7 3.6 4.8 3 6 3 10 15 3 M-C2E-B25 – – –
20BE3P9 0 3 2 4 50 3.0 3.1 3.9 4.3 5.9 6 9 6 15 15 7 M-C2E-B40 M-D8E-B40 – –
20BE6P1 0 5 3 4 50 5.3 5.5 6.1 6.7 9.2 9 12 9 20 20 15 M-C2E-B63 M-D8E-B63 – –
20BE9P0 0 7.5 5 4 50 7.8 8.1 9 9.9 13.5 10 20 10 35 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BE011 1 10 7.5 4 50 9.9 10.2 11 13.5 18 15 25 15 40 40 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BE017 1 15 10 4 50 15.4 16.0 17 18.7 25.5 20 40 20 60 50 20 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BE022 2 20 15 4 50 20.2 21.0 22 25.5 34 30 50 30 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BE027 2 25 20 4 50 24.8 25.7 27 33 44 35 60 35 100 100 50 – – M-F8E-C25 -CMN-2500
20BE032 3 30 25 4 50 29.4 30.5 32 40.5 54 40 70 40 125 125 50 – – M-F8E-C32 -CMN-4000
20BE041 3 40 30 4 50 37.6 39.1 41 48 64 50 90 50 150 150 100 – – M-F8E-C45 -CMN-4000
20BE052 3 50 40 4 50 47.7 49.6 52 61.5 82 60 110 60 200 200 100 – – – -CMN-6300
20BE062 4 60 50 2 50 58.2 60.5 62 78 104 80 125 80 225 225 100 – – – -CMN-6300
20BE077 5 75 – 2 50 72.3 75.1 77 85 116 90 150 90 300 300 100 – – – -CMN-9000
– 60 2 50 58.2 60.5 63 94 126 90 125 90 250 250 100 – – – -CMN-6300
20BE099 5 100 – 2 40 92.9 96.6 99 109 126 125 200 125 375 375 150 – – – –
– 75 2 40 72.3 75.1 77 116 138 100 175 100 300 300 100 – – – -CMN-9000
20BE125 6 125 – 2 50 117 122 125 138 188 150 250 150 375 375 250 – – – –
– 100 2 50 93 96.6 99 149 198 125 200 125 375 375 150 – – – –
20BE144 6 150 – 2 50 135 141 144 158 216 175 300 175 400 400 250 – – – –
– 125 2 50 117 122 125 188 250 150 275 150 375 375 250 – – – –

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
