Programming and Parameters 3-11
Advanced Fan/Pump Parameter View
(1)
– Standard Control Option
Parameter 196 [Param Access Lvl] set to option 4 ā€œAdv Fan/Pump.ā€
(1)
Only available on Standard Control drives with firmware version 3.001 or above.
File Group Parameters
Monitor Metering Output Freq 001
Commanded Freq 002
Output Current 003
Output Power 007
Elapsed MWh 009
Elapsed Run Time 010
DC Bus Voltage 012
Analog In1 Value 016
Analog In2 Value 017
Motor Control Motor Data Motor NP Volts 041
Motor NP FLA 042
Motor NP Hertz 043
Motor NP RPM 044
Motor NP Power 045
Mtr NP Pwr Units 046
Torq Attributes Torque Perf Mode 053
Maximum Voltage 054
Maximum Freq 055
Volts per Hertz Start/Acc Boost 069
Run Boost 070
Break Voltage 071
Break Frequency 072
Speed
Command
Spd Mode &
Limits
Speed Mode 080
Minimum Speed 081
Maximum Speed 082
Overspeed Limit 083
Skip Frequency 1 084
Skip Frequency 2 085
Skip Frequency 3 086
Skip Freq Band 087
Speed
References
Speed Ref A Sel 090
Speed Ref A Hi 091
Speed Ref A Lo 092
Speed Ref B Sel 093
Speed Ref B Hi 094
Speed Ref B Lo 095
Discrete
Speeds
Preset Speed 2-4 102-104
Process PI PI Configuration 124
PI Control 125
PI Reference Sel 126
PI Setpoint 127
PI Feedback Sel 128
PI Integral Time 129
PI Prop Gain 130
PI Lower Limit 131
PI Upper Limit 132
PI Preload 133
PI Status 134
PI Ref Meter 135
PI Fdback Meter 136
PI Error Meter 137
PI Output Meter 138
Dynamic
Control
Ramp Rates Accel Time 1 140
Accel Time 2 141
Decel Time 1 142
Decel Time 2 143
S Curve % 146
Load Limits Current Lmt Val 148 PWM Frequency 151
Stop/Brake
Modes
Stop Mode A 155
Restart Modes Start At PowerUp 168
Flying Start En 169
Flying StartGain 170
Auto Rstrt Tries 174
Auto Rstrt Delay 175
Sleep Wake-Mode 178
Sleep-Wake Ref 179
Wake Level 180
Wake Time 181
Sleep Level 182
Sleep Time 183
Power Loss Power Loss Mode 184 Power Loss Time 185
Utility Direction Config Direction Mode 190
HIM Ref Config Save HIM Ref 192 Man Ref Preload 193
Drive Memory Param Access Lvl 196 Reset To Defalts 197 Language 201
Diagnostics Start Inhibits 214
Dig In Status 216
Dig Out Status 217
Inputs &
Outputs
Analog Inputs Anlg In Config 320
Anlg In Sqr Root 321
Analog In 1 Hi 322
Analog In 2 Hi 325
Analog In 1 Lo 323
Analog In 2 Lo 326
Anlg In 1 Loss 324
Anlg In 2 Loss 327
Analog Outputs Anlg Out Config 340
Analog Out1 Sel 342
Analog Out1 Hi 343
Analog Out1 Lo 344
Digital Inputs Digital In1-6 Sel 361-366
Digital Outputs Digital Out1 Sel 380
Digital Out2 Sel 384
Dig Out1 Level 381
Dig Out2 Level 385
Dig Out1 OnTime 382
Dig Out2 OnTime 386
Dig Out1 OffTime 383
Dig Out2 OffTime 387
Monitor
Motor Control
Speed Command
D
ynam
ic Control
U
tility
Inputs & O
utputs
