3-46 Programming and Parameters
UTILITY
Faults
238 [Fault Config 1]
Enables/disables annunciation of the listed faults.
240 [Fault Clear]
Resets a fault and clears the fault queue.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“Clear Faults”
“Clr Flt Que”
241 [Fault Clear Mode]
Enables/disables a fault reset (clear
faults) attempt from any source. This
does not apply to fault codes which are
cleared indirectly via other actions.
Default:
Options:
1
0
1
“Enabled”
“Disabled”
“Enabled”
242 [Power Up Marker]
Elapsed hours since initial drive power
up. This value will rollover to 0 after the
drive has been powered on for more than
the max value shown. For relevance to
most recent power up see [Fault x Time].
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hr
0.0/429496.7 Hr
0.0000/214748.3647 Hr
0.0001 Hr
0.1 Hr
244
246
248
250
252
254
256
258
243
245
247
249
251
253
255
257
[Fault 1 Code]
[Fault 2 Code]
[Fault 3 Code]
[Fault 4 Code]
[Fault 5 Code]
[Fault 6 Code]
[Fault 7 Code]
[Fault 8 Code]
A code that represents the fault that
tripped the drive. The codes will appear
in these parameters in the order they
occur ([Fault 1 Code] = the most recent
fault).
Default:
Min/Max:
Units:
Read Only
0/65535
0
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
1x10001000x00xxx
10 01234567891112131415
1 =Enabled
0 =Disabled
x =Reserved
Bit #
Factory Default Bit Values
Power Loss
UnderVoltage
Motor OverLd
Shear Pin
AutRst Tries
Decel Inhibt
Motor Therm *
In PhaseLoss *
Load Loss *
ShearPNo Acc *
Out PhaseLoss *
* Vector firmware 3.001 & later
32
Vector
v3
Vector
To Next Page
