Programming and Parameters 3-47
UTILITY
Faults
244
246
248
250
252
254
256
258
[Fault 1 Time]
[Fault 2 Time]
[Fault 3 Time]
[Fault 4 Time]
[Fault 5 Time]
[Fault 6 Time]
[Fault 7 Time]
[Fault 8 Time]
The time between initial drive power up
and the occurrence of the associated trip
fault. Can be compared to [Power Up
Marker] for the time from the most recent
power up.
[Fault x Time] – [Power Up Marker] =
Time difference to the most recent power
up. A negative value indicates fault
occurred before most recent power up. A
positive value indicates fault occurred
after most recent power up.
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hr
0.0000/214748.3647 Hr
0.0001 Hr
242
Alarms
259 [Alarm Config 1]
Enables/disables alarm conditions that will initiate an active drive alarm.
261 [Alarm Clear]
Resets all [Alarm 1-8 Code] parameters
to zero.
Default:
Options:
0
0
1
“Ready”
“Ready”
“Clr Alrm Que”
262
263
264
265
266
267
268
269
262
263
264
265
266
267
268
269
[Alarm 1 Code]
[Alarm 2 Code]
[Alarm 3 Code]
[Alarm 4 Code]
[Alarm 5 Code]
[Alarm 6 Code]
[Alarm 7 Code]
[Alarm 8 Code]
A code that represents a drive alarm. The
codes will appear in the order they occur
(first 4 alarms in – first 4 out alarm
queue). A time stamp is not available with
alarms.
Default:
Min/Max:
Units:
Read Only
0/65535
1
261
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
32
v3
111111x11110000x
10 01234567891112131415
1 =Enabled
0 =Disabled
x =Reserved
Bit #
Factory Default Bit Values
Prechrg Actv
UnderVoltage
Power Loss
Str At PwrUp
Anlg In Loss
IntDBRes OH
Drv OL Lvl 1
Drv OL Lvl 2
Decel Inhibt
Waking
Motor Therm *
In Phase Loss *
Load Loss *
Ground Warn *
* Vector firmware 3.001 & later
