Allen-Bradley PowerFlex 700H Programming Manual

Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 21
Programming and Parameters Chapter 2
Motor Control File
MONITOR
Metering
023 [Speed Reference]
Summed value of ramped speed, process PI and
droop.
Default:
Min/Max:
Units:
Read Only
–/+320.0 Hz
–/+19200.0 RPM
0.1 Hz
0.1 RPM
079
024 [Commanded Torque]
Final torque reference value after limits and
filtering are applied. Percent of motor rated
torque.
Note: Added for firmware revision 4.001.
Default:
Min/Max:
Units:
Read Only
–/+800.0%
0.1%
053
025 [Speed Feedback]
This parameter displays the estimated value of
actual motor speed.
Default:
Min/Max:
Units:
Read Only
–/+320.0 Hz
–/+19200.0 RPM
0.1 Hz
0.1 RPM
Drive Data
026 [Rated kW]
Drive power rating.
Default:
Min/Max:
Units:
Read Only
0.00/3000.00 kW
0.01 kW
027 [Rated Volts]
The drive input voltage class (208, 240, 400 etc.).
Default:
Min/Max:
Units:
Read Only
0.0/690.0 VAC
0.1 VAC
028 [Rated Amps]
The drive rated output current.
Default:
Min/Max:
Units:
Read Only
0.0/6553.5 Amps
0.1 Amps
029 [Control SW Ver]
Main Control Board software revision.
Default:
Min/Max:
Units:
Read Only
0.000/255.255
0.001
File Group No.
Parameter Name & Description Values
Related
32
32
File Group No.
Parameter Name & Description Values
Related
MOTOR CONTROL
Motor Data
040 [Motor Type]
Set to match the type of motor connected.
Default:
Options:
0
0
“Induction”
“Induction”
053
041 [Motor NP Volts]
Set to the motor nameplate rated volts.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Volts]
0.1 VAC
042 [Motor NP FLA]
Set to the motor nameplate rated full load amps.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Amps] × 2
0.1 Amps
047
048
043 [Motor NP Hertz]
Set to the motor nameplate rated frequency.
Default:
Min/Max:
Units:
Based on Drive Rating
5.0/320.0 Hz
0.1 Hz
044 [Motor NP RPM]
Set to the motor nameplate rated RPM.
Default:
Min/Max:
Units:
Based on Drive Rating
60.0/19200.0 RPM
1.0 RPM
045 [Motor NP Power]
Set to the motor nameplate rated power.
Default:
Min/Max:
Units:
Based on Drive Rating
0.00/5000.00
0.01 kW/HP
See [Mtr NP Pwr Units]
046
