Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 71
Troubleshooting Chapter 3
Fault Subcodes
Fault Subcodes can be viewed in parameters 543, 545, 547, 549, 551, 553, 555,
and 557 [Fault x Subcode]. Each of these parameters corresponds with
parameters 243, 245, 247, 249, 251, 253, 255, and 257 [Fault x Code],
respectively. For example, if parameter 243 [Fault 1 Code] displays “5” and
parameter 543 [Fault 1 Subcode] displays “273”, an over voltage fault (F5) has
occurred in the power unit of the drive.
Table 3 - Precharge Active Fault (F1) Subcodes
Table 4 - Under Voltage Fault (F4) Subcodes
Table 5 - Over Voltage Fault (F5) Subcodes
Table 6 - Motor Stall Fault (F6) Subcode
Table 7 - Heatsink Over Temperature Fault (F8) Subcodes
IGBT OverTemp 9 UnderVoltage 4
IGBT Temp Hw 31 UserSetCflct 139
Input Phase 17 UserSet Timer 99
IntDB OvrHeat 148 VHz Neg Slope 26
InverterFault 14 Waking 149
Load Loss 15 Zero Divide 54
Name No.
Fault
Alarm
Name No.
Fault
Alarm
Subcode Description
273 The precharge circuit in the power unit is active.
289 The precharge circuit in power unit 1 is active.
305 The precharge circuit in power unit 2 is active.
Subcode Description
273 The DC Bus voltage in the power unit is too low while the drive is in a run state.
529 The DC Bus voltage in the power unit is too low while the drive is in a run state.
545 The DC Bus voltage in power unit 1 is too low while the drive is in a run state.
561 The DC Bus voltage in power unit 2 is too low while the drive is in a run state.
785 The DC Bus voltage in the power unit fell too low during a fast stop.
Subcode Description
273 There is an over voltage in the power unit.
289 There is an over voltage in power unit 1.
276 There is an over voltage in power unit 2.
277 There is an over voltage in the power unit.
Subcode Description
400 The motor is operating at high current and low frequency and is not accelerating.
Subcode Description
272, 273 There is a heatsink over temperature in the power unit.
274 There is a heatsink over temperature on the Power board of the power unit.
275 There is a heatsink over temperature in the U phase of the power unit (typically frame 11 and 13 drives).
276 There is a heatsink over temperature in the V phase of the power unit (typically frame 11 and 13 drives).
277 There is a heatsink over temperature in the W phase of the power unit (typically frame 11 and 13 drives).
288, 289 There is a heatsink over temperature in power unit 1 (typically frame 12 and 14 drives).
290 There is a heatsink over temperature on the Power board of power unit 1 (typically frame 12 and 14 drives).
291 There is a heatsink over temperature in the U phase of power unit 1 (typically frame 12 and 14 drives).
292 There is a heatsink over temperature in the V phase of power unit 1 (typically frame 12 and 14 drives).
