Chapter 2 Programming and Parameters
Monitor File
File Group No.
Parameter Name & Description Values
Related
MONITOR
Metering
001 [Output Freq]
Output frequency present at U/T1, V/T2 & W/T3.
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Freq]
0.1 Hz
002 [Commanded Speed]
Value of the active Speed/Frequency Reference.
Displayed in Hz or RPM, depending on value of
[Speed Units].
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
0.1 RPM
079
003 [Output Current]
The total output current present at U/T1, V/T2 &
W/T3.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Amps x 2
0.1 Amps
004 [Torque Current]
Based on the motor, the amount of current that is
in phase with the fundamental voltage
component.
Default:
Min/Max:
Units:
Read Only
Drive Rating x –2/+2
0.1 Amps
005 [Flux Current]
Amount of current that is out of phase with the
fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating x –2/+2
0.1 Amps
006 [Output Voltage]
Output voltage present at terminals U/T1, V/T2 &
W/T3.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Volts
0.1 VAC
007 [Output Power]
Output power present at U/T1, V/T2 & W/T3.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated kW x 2
0.1 kW
008 [Output Powr Fctr]
Output power factor.
Default:
Min/Max:
Units:
Read Only
0.00/1.00
0.01
009 [Elapsed MWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 MWh
0.1 MWh
010 [Elapsed Run Time]
Accumulated time drive is outputting power.
Default:
Min/Max:
Units:
Read Only
0.0/214748364.0 Hrs
0.1 Hrs
011 [MOP Reference]
Value of the signal at MOP (Motor Operated
Potentiometer).
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
0.1 RPM
079
012 [DC Bus Voltage]
Present DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Based on Drive Rating
0.1 VDC
013 [DC Bus Memory]
Approximate full load DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Based on Drive Rating
0.1 VDC
016
017
[Analog In1 Value]
[Analog In2 Value]
Value of the signal at the analog inputs.
Default:
Min/Max:
Units:
Read Only
0.000/20.000 mA
–/+10.000V
0.001 mA
0.001 Volt
022 [Ramped Speed]
Value of commanded speed after Accel/Decel, and
S-Curve are applied.
Default:
Min/Max:
Units:
Read Only
–/+320.0 Hz
–/+19200.0 RPM
0.1 Hz
0.1 RPM
079
