Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 19
Programming and Parameters Chapter 2
Utility
Direction Config Direction Mode 190
HIM Ref Config Save HIM Ref 192 Man Ref Preload 193
MOP Config Save MOP Ref 194 MOP Rate 195
Drive Memory Param Access Lvl 196
Reset To Defalts 197
Load Frm Usr Set 198
Save To User Set 199
Reset Meters 200
Language 201
Voltage Class 202
Drive Checksum 203
Dyn UserSet Cnfg 204
Dyn UserSet Sel 205
Dyn UserSet Actv 206
Diagnostics Drive Status 1 209
Drive Status 2 210
Drive Alarm 1 211
Drive Alarm 2 212
Speed Ref Source 213
Start Inhibits 214
Last Stop Source 215
Dig In Status 216
Dig Out Status 217
Drive Temp 218
Motor OL Count 220
Fault Frequency 224
Fault Amps 225
Fault Bus Volts 226
Status 1 @ Fault 227
Status 2 @ Fault 228
Alarm 1 @ Fault 229
Alarm 2 @ Fault 230
Testpoint 1 Sel 234
Testpoint 1 Data 235
Testpoint 2 Sel 236
Testpoint 2 Data 237
Faults Fault Config 1 238
Fault Clear 240
Fault Clear Mode 241
Power Up Marker 242
Fault 1 Code 243
Fault 2 Code 245
Fault 3 Code 247
Fault 4 Code 249
Fault 5 Code 251
Fault 6 Code 253
Fault 7 Code 255
Fault 8 Code 257
Fault 1 Time 244
Fault 2 Time 246
Fault 3 Time 248
Fault 4 Time 250
Fault 5 Time 252
Fault 6 Time 254
Fault 7 Time 256
Fault 8 Time 258
Fault 1 SubCode 543
Fault 2 SubCode 545
Fault 3 SubCode 547
Fault 4 SubCode 549
Fault 5 SubCode 551
Fault 6 SubCode 553
Fault 7 SubCode 555
Fault 8 SubCode 557
Alarms Alarm Config 1 259
Alarm Clear 261
Alarm1 Code 262
Alarm2 Code 263
Alarm3 Code 264
Alarm4 Code 265
Alarm5 Code 266
Alarm6 Code 267
Alarm7 Code 268
Alarm8 Code 269
Communication
Comm Control Drive Logic Rslt 271
Drive Ref Rslt 272
Drive Ramp Rslt 273
DPI Port Sel 274
DPI Port Value 275
Masks/Owners Logic Mask 276
Start Mask 277
Jog Mask 278
Direction Mask 279
Reference Mask 280
Accel Mask 281
Decel Mask 282
Fault Clr Mask 283
MOP Mask 284
Local Mask 285
Stop Owner 288
Start Owner 289
Jog Owner 290
Direction Owner 291
Reference Owner 292
Accel Owner 293
Decel Owner 294
Fault Clr Owner 295
MOP Owner 296
Local Owner 297
Datalinks Data In A1 300
Data In A2 301
Data In B1 302
Data In B2 303
Data In C1 304
Data In C2 305
Data In D1 306
Data In D2 307
Data Out A1 310
Data Out A2 311
Data Out B1 312
Data Out B2 313
Data Out C1 314
Data Out C2 315
Data Out D1 316
Data Out D2 317
Security Port Mask Act 595
Write Mask Cfg 596
Write Mask Act 597 Logic Mask Act 598
Inputs/Outputs
Analog Inputs Anlg In Config 320
Anlg In Sqr Root 321
Analog In1 Hi 322
Analog In2 Hi 325
Analog In1 Lo 323
Analog In2 Lo 326
Analog In1 Loss 324
Analog In2 Loss 327
Analog Outputs Anlg Out Config 340
Anlg Out Absolut 341
Analog Out1 Sel 342
Analog Out2 Sel 345
Analog Out1 Hi 343
Analog Out2 Hi 346
Analog Out1 Lo 344
Analog Out2 Lo 347
Anlg Out1 Scal 354
Anlg Out2 Scal 355
Anlg1 Out Setpt 377
Anlg2 Out Setpt 378
Digital Inputs Digital In1 Sel 361
Digital In2 Sel 362
Digital In3 Sel 363
Digital In4 Sel 364
Digital In5 Sel 365
Digital In6 Sel 366
20C-DG1 Remove 358
20C-DG1 Status 359
Digital Outputs Digital Out1 Sel 380
Dig Out1 Level 381
Dig Out1 OnTime 382
Dig Out1 OffTime 383
Digital Out2 Sel 384
Dig Out2 Level 385
Dig Out2 OnTime 386
Dig Out2 OffTime 387
Digital Out3 Sel 388
Dig Out3 Level 389
Dig Out3 OnTime 390
Dig Out3 OffTime 391
Dig Out Setpt 379
File Group Parameters
Utility
Communication
Inputs & Outputs
To Next Page
