Allen-Bradley PowerFlex 700H Programming Manual

18 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
Advanced Parameter View
Parameter 196 [Param Access Lvl] set to option 1 “Advanced.”
Inputs/Outputs
Analog Inputs Anlg In Config 320
Analog In1 Hi 322
Analog In1 Lo 323
Analog In2 Hi 325
Analog In2 Lo 326
Analog Outputs Analog Out1, 2 Sel 342
Analog Out1 Hi 343
Analog Out1, 2 Lo 344
Analog Out1, 2 Sel 345
Analog Out2 Hi 346
Analog Out1, 2 Lo 347
Digital Inputs Digital In1 Sel 361
Digital In2 Sel 362
Digital In3 Sel 363
Digital In4 Sel 364
Digital In5 Sel 365
Digital In6 Sel 366
20C-DG1 Remove 358
20C-DG1 Status 359
Digital Outputs Digital Out1 Sel 380
Digital Out2 Sel 384
Digital Out3 Sel 388
Dig Out1 Level 381
Dig Out2 Level 385
Dig Out3 Level 389
File Group Parameters
Monitor
Metering Output Freq 001
Commanded Speed 002
Ramped Speed 022
Speed Reference 023
Commanded Torque 024
Output Current 003
Torque Current 004
Flux Current 005
Output Voltage 006
Output Power 007
Output Powr Fctr 008
Elapsed MWh 009
Elapsed Run Time 010
MOP Reference 011
DC Bus Voltage 012
DC Bus Memory 013
Analog In1 Value 016
Analog In2 Value 017
Speed Reference 023
Speed Feedback 025
Drive Data Rated kW 026
Rated Volts 027
Rated Amps 028 Control SW Ver 029
Motor Control
Motor Data Motor Type 040
Motor NP Volts 041
Motor NP FLA 042
Motor NP Hertz 043
Motor NP RPM 044
Motor NP Power 045
Mtr NP Pwr Units 046
Motor OL Hertz 047
Motor OL Factor 048
Motor Poles 049
Motor OL Mode 050
Torq Attributes Motor Cntl Sel 053
Maximum Freq 055
Flux Up Mode 057
Flux Up Time 058
SV Boost Filter 059
Autotune 061
IR Voltage Drop 062
Flux Current Ref 063
Compensation 056
Volts per Hertz Start/Acc Boost 069 Break Voltage 071 Break Frequency 072
Speed Command
Spd Mode/Limits Speed Units 079
Feedback Select 080
Minimum Speed 081
Maximum Speed 082
Overspeed Limit 083
Skip Frequency 1 084
Skip Frequency 2 085
Skip Frequency 3 086
Skip Freq Band 087
Speed/Torque Mod 088
Rev Speed Limit 454
Speed References Speed Ref A Sel 090
Speed Ref A Hi 091
Speed Ref A Lo 092
Speed Ref B Sel 093
Speed Ref B Hi 094
Speed Ref B Lo 095
TB Man Ref Sel 096
TB Man Ref Hi 097
TB Man Ref Lo 098
Discrete Speeds Jog Speed 1 100
Preset Speed 1 101
Preset Speed 2 102
Preset Speed 3 103
Preset Speed 4 104
Preset Speed 5 105
Preset Speed 6 106
Preset Speed 7 107
Jog Speed 2 108
Speed Trim Trim In Select 117
Trim Out Select 118
Trim Hi 119
Trim Lo 120
Trim % Setpoint 116
Slip Comp Slip RPM @ FLA 121 Slip RPM Meter 123
Process PI PI Configuration 124
PI Control 125
PI Reference Sel 126
PI Setpoint 127
PI Feedback Sel 128
PI Integral Time 129
PI Prop Gain 130
PI Lower Limit 131
PI Upper Limit 132
PI Preload 133
PI Status 134
PI Ref Meter 135
PI Fdback Meter 136
PI Error Meter 137
PI Output Meter 138
PI Reference Hi 460
PI Reference Lo 461
PI Feedback Hi 462
PI Feedback Lo 463
PI Output Gain 464
Dynamic Control
Ramp Rates Accel Time 1 140
Accel Time 2 141
Decel Time 1 142
Decel Time 2 143
S Curve % 146
Load Limits Current Lmt Sel 147
Current Lmt Val 148
Current Lmt Gain 149
Drive OL Mode 150
PWM Frequency 151
Droop RPM @ FLA 152
Stop/Brake Modes Stop/Brk Mode A 155
Stop/Brk Mode B 156
DC Brk Lvl Sel 157
DC Brake Level 158
DC Brake Time 159
Bus Reg Ki 160
Bus Reg Mode A 161
Bus Reg Mode B 162
DB Resistor Type 163
Bus Reg Kp 164
Bus Reg Kd 165
DB While Stopped 145
Fan Control 465
Restart Modes Start At PowerUp 168
Flying Start En 169
Auto Rstrt Tries 174
Auto Rstrt Delay 175
Sleep Wake Mode 178
Sleep Wake Ref 179
Wake Level 180
Wake Time 181
Sleep Level 182
Sleep Time 183
Powerup Delay 167
Power Loss Power Loss Mode 184
Power Loss Time 185
Power Loss Volts 186 Shear Pin Time 189
