UTILITY
Alarms
259 [Alarm Config 1]
Enables/disables alarm conditions that will initiate an active drive alarm.
Note: Bits 14 and 15 were added for firmware revision 2.001.
1 = Condition True/Enabled
0 = Condition False/Disabled
261 [Alarm Clear]
Resets all [Alarm x Code] parameters to zero.
Default:
Options:
0
0
1
“Ready”
“Ready”
“Clr Alrm Que”
262
263
264
265
266
267
268
269
262
263
264
265
266
267
268
269
[Alarm 1 Code]
[Alarm 2 Code]
[Alarm 3 Code]
[Alarm 4 Code]
[Alarm 5 Code]
[Alarm 6 Code]
[Alarm 7 Code]
[Alarm 8 Code]
A code that represents a drive alarm. The codes
will appear in the order they occur (first 4 alarms
in – first 4 out alarm queue). A time stamp is not
available with alarms.
Default:
Min/Max:
Units:
Read Only
0/255
1
261
File
Group
No.
Parameter Name & Description Values
Related
Name
Gate Disable
PTC Config
Load Loss
Phase Loss
Motor Therm
Waking
Decel Inhibt
Drv OL Lvl 2
Drv OL Lvl 1
Heatsink Temp
IntDBRes OH
Anlg in Loss
Str At PwrUp
Power Loss
UnderVoltage
Prechrg Actv
Default0001111001111111
Bit 1514131211109876543210
