Allen-Bradley PowerFlex 700H Programming Manual

Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 51
Programming and Parameters Chapter 2
INPUTS/OUTPUTS
Analog Outputs
341 [Anlg Out Absolut]
Selects whether the signed value or absolute value of a parameter is used before being scaled to
drive the analog output.
1 = Absolute
0 = Signed
342
345
[Analog Out1 Sel]
[Analog Out2 Sel]
Selects the source of the value that drives the
analog output.
Default:
Options:
0
–>
“Output Freq”
(See table below)
001
002
003
004
005
007
006
012
135
136
137
138
220
343
346
[Analog Out1 Hi]
[Analog Out2 Hi]
Sets the analog output value when the source
value is at maximum.
Note: The Min. value was changed from
4.000 mA…0.000 mA for firmware revision
3.001.
Default:
Min/Max:
Units:
20.000 mA, 10.000 Volts
0.000/20.000 mA
–/+10.000V
0.000/10.000V
0.001 mA
0.001 Volt
340
342
345
344
347
[Analog Out1 Lo]
[Analog Out2 Lo]
Sets the analog output value when the source
value is at minimum.
Note: The Min. value was changed from
4.000 mA…0.000 mA for firmware revision
3.001.
Default:
Min/Max:
Units:
0.000 mA, 0.000 Volts
0.000/20.000 mA
–/+10.000V
0.000/10.000V
0.001 mA
0.001 Volt
340
342
345
354
355
[Anlg Out1 Scale]
[Anlg Out2 Scale]
Sets the high value for the range of analog output
scale. Entering 0.0 will disable this scale and max
scale will be used. Example: If [Analog Outx Sel]
= “Commanded Freq,” a value of 150 = 150%
scale in place of the default 200%.
Default:
Min/Max:
Units:
0.0
[Analog Outx Sel]
0.1
342
345
377
378
[Anlg1 Out Setpt]
[Anlg2 Out Setpt]
Sets the analog output value from a
communication device. Example: Set [Data In Ax]
to “377” (value from communication device).
Then set [Analog Outx Sel] to “Param Cntl.”
Default:
Min/Max:
Units:
0.000 mA, 0.000 Volts
0.000/20.000 mA
–/+10.000V
0.001 mA
0.001 Volt
342
345
File Group No.
Parameter Name & Description Values
Related
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog Out2 Analog Out1
Defaultxxxxxxxxxxxxxx11
Bit 1514131211109876543210
Options
[Analog Outx Lo] Value
[Analog Outx Hi] ValuePar 341 = Signed Par 341 = Absolute
0
1
2
3
4
5
6
7
8
9
10
11
12
13…15
16
17…23
24
“Output Freq”
“Command Freq”
“Output Amps”
“Torque Amps”
“Flux Amps”
“Output Power”
“Output Volts”
“DC Bus Volt”
“PI Reference”
“PI Feedback”
“PI Error”
“PI Output”
“%Motor OL”
“Reserved”
“Speed Ref”
“Reserved”
“Param Cntl”
–[Maximum Speed]
–[Maximum Speed]
0 Amps
–200% Rated
0 Amps
0 kW
0 Volts
0 Volts
–100%
–100%
–100%
–100%
0%
–
–[Maximum Speed]
–
0 Hz
0 Hz/RPM
0 Amps
0 Amps
0 Amps
0 kW
0 Volts
0 Volts
0%
0%
0%
0%
0%
–
0 Hz
–
+[Maximum Speed]
+[Maximum Speed]
200% Rated
200% Rated
200% Rated
200% Rated
120% Rated Input Volts
200% Rated Input Volts
100%
100%
100%
100%
100%
–
+[Maximum Speed]
–
32
