76 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 3 Troubleshooting
Table 22 - NVS Read Checksum Fault (F47) Subcode
Table 23 - Motor Over Temperature Fault (F16) Subcode
Table 24 - Power Unit Fault (F70) Subcodes
Table 25 - Hardware Enable Fault (F94) Subcode
Table 26 - Parameter Checksum Fault (F100) Subcodes
Table 27 - Main Control Board - Power Board Configuration Fault (F106) Subcode
370 The Star Coupler board has been changed, added, removed, has experienced a checksum error, or is new
and the parameters for the device/board remain unchanged (typically frame 12 and 14 drives).
528 The power level in power unit 2 is not equal to the power level in power unit 1 after a microprocessor reset
(typically frame 12 and 14 drives).
561 The power level in power unit 2 is not equal to the power level in power unit 1 after a microprocessor reset
(typically frame 12 and 14 drives).
Subcode Description
322 An operating time or energy counter checksum error has occurred on the Control board.
Subcode Description
400 The motor is operating at high current and low frequency and is not accelerating.
Subcode Description
272, 273 There is saturation in the power unit.
275 There is saturation in the U phase of the power unit (typically frame 11 and 13 drives).
276 There is saturation in the V phase of the power unit (typically frame 11 and 13 drives).
277 There is saturation in the W phase of the power unit (typically frame 11 and 13 drives).
288, 289 There is saturation in power unit 1 (typically frame 12 and 14 drives).
291 There is saturation in the U phase of power unit 1 (typically frame 14 drives).
292 There is saturation in the V phase of power unit 1 (typically frame 14 drives).
293 There is saturation in the W phase of power unit 1 (typically frame 14 drives).
304, 305 There is saturation in power unit 2 (typically frame 12 and 14 drives).
307 There is saturation in the U phase of power unit 2 (typically frame 14 drives).
308 There is saturation in the V phase of power unit 2 (typically frame 14 drives).
309 There is saturation in the W phase of power unit 2 (typically frame 14 drives).
Subcode Description
338 An hardware enable signal is missing from the control terminal block.
Subcode Description
322 A firmware interface power down variable checksum error has occurred on the Control board.
578 A firmware interface variable checksum error has occurred on the Control board.
834 A system powerdown variable checksum error (panel menu index, fault history pointer) has occurred on
the Control board.
1090 A system parameter checksum error (multimonitor, panel default pages) has occurred on the Control
board.
1346 An application defined powerdown, variable checksum error has occurred on the Control board.
1602 An application defined powerdown, variable checksum error has occurred on the Control board.
2626 A system parameter checksum error (fault history entries, device valid, system menu parameters) has
occurred on the Control board.
Subcode Description
385 The software and the power unit are incompatible.
Subcode Description
