PowerFlex® 700S Drives - Phase I Control (Frame Sizes 9 & 10) 27
Figure 3 Frame 9 - X50 Terminal Block Location
Figure 4 Frame 10 - X50 Terminal Block Location
X50
X50 Terminal Block
X50 Terminal Block
Control Frame
Note: 700S control
mounting plate and
HIM not shown for
clarity only
