48 PowerFlex® 700S Drives - Phase I Control (Frame Sizes 9 & 10)
222 Motor Fdbk Sel
Enter or write a value to select the primary motor speed feedback device.
Default:
Options:
0
0
1
2
3
“Encoder 0”
“Encoder 0” 4 “Motor Sim”
“Encoder 1” 5 “FB Opt Port0”
“Sensorless” 6 “FB Opt Port1”
“Reserved”
800 Anlg In1 Data
Displays the value of Analog Input 1. This is the final value (after conversion, offsetting,
scaling and filtering).
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
802 Anlg In1 Scale
Scales the range of Analog Input 1 to the range of Parameter 800 [Anlg In1 Data].
Parameter 801 [Anlg In1 Volts] is multiplied by this number to produce the input to the
lead lag filter function.
Par 802 = 1, Par 800 = 10 when 10V is applied.
Units:
Default:
Min/Max:
/1v
0.0000
-/+2200000000.0000
✓ RW Real
803 Anlg In1 Offset
Applies an offset to Analog Input 1. The output of the analog to digital conversion is
summed with this number to produce Parameter 801 [Anlg In1 Volts]. This is used to zero
out the analog input.
Units:
Default:
Min/Max:
Volt
0.0000
-/+20.0000
✓ RW Real
806 Anlg In2 Data
Displays the value of Analog Input 2. This is the final value (after conversion, offsetting,
scaling and filtering).
Units:
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
808 Anlg In2 Scale
Scales the range of Analog Input 1 to the range of Parameter 806 [Anlg In2 Data].
Parameter 807 [Anlg In2 Volts] is multiplied by this number to produce the input to the
lead lag filter function.
Units:
Default:
Min/Max:
/1v
0.0000
-/+2200000000.0000
✓ RW Real
809 Anlg In2 Offset
Applies an offset to Analog Input 1. The output of the analog to digital conversion is
summed with this number to produce Parameter 807 [Anlg In2 Volts].
Units:
Default:
Min/Max:
Volt
0.0000
-/+20.0000
✓ RW Real
838 DigIn1 Sel
Enter or write a value to select the function of digital input 1.
Default:
Options:
0
0
1
2
3
4
5
6
7
“Not Used”
“Not Used” 8 “Fwd/Reverse”
“Normal Stop” 9 “CurLim Stop”
“Start” 10 “Coast Stop”
“Run” 11 “Aux Fault”
“Clear Faults” 12 “AuxFault Inv”
“Stop - CF” 13 “User Select”
“Jog 1” 14 “PreChrg/Disc”
“Jog 2”
839 DigIn2 Sel
Enter or write a value to select the function of digital input 2.
Default:
Options:
4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
“Norm Stop-CF”
“Not Used” 14 “Reserved”
“Normal Stop”” 15 “Reserved”
“Start” 16 “Reserved”
“Run” 17 “Reserved”
“Clear Faults” 18 “Reserved”
“Stop-CF” 19 “Reserved”
“Jog 1” 21 “Reserved”
“Jog 2” 22 “Reserved”
“Fwd/Reverse” 23 “Logix Motion”
“CurLim Stop” 24 “+Hrd OvrTrvl”
“Coast Stop” 25 “-Hrd OvrTrvl”
“Aux Fault”
“AuxFault Inv”
“User Select”
840 DigIn3 Sel
Enter or write a value to select the function of digital input 3.
Default:
Options:
0
0
1
2
3
4
5
6
7
8
9
10
11
12
“Not Used”
“Not Used” 13 “User Select”
“Normal Stop” 14 “Reserved”
“Start” 15 “Reserved”
“Run” 16 “Reserved”
“Clear Faults” 17 “Reserved”
“Stop-CF” 18 “Reserved”
“Jog 1” 19 “Reserved”
“Jog 2” 21 “Reserved”
“Fwd/Reverse” 22 “Reserved”
“CurLim Stop” 23 “Logix Motion”
“Coast Stop” 24 “+Hrd OvrTrvl”
“Aux Fault” 25 “-Hrd OvrTrvl”
“AuxFault Inv”
(1) No. - Parameter Number. = parameter value cannot be changed until the drive is stopped.
(2) Name - Parameter name as it appears in DriveExecutive™ software.
Description - Brief description of parameter function.
(3) Values - Define the various operating characteristics of the parameter. There are 3 types of Values: ENUM, Bit and Numeric.
No.
(1)
Name
Description
(2)
Values
(3)
Linkable Read-Write Data Type
