Allen-Bradley PowerFlex 755 IP00 - Dimensions

28 Rockwell Automation Publication 750-IN020D-EN-P - May 2017
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Dimensions
Figure 10 - Drive Unit Dimensions - AC Input
185.9 (7.32)
316.4 (12.46) 424.9 (16.73)
129.7 (5.11)
409.7 (16.13)
643.3 (25.33)
0.0 (0.00)0.0 (0.00) 0.0 (0.00)
12.7 (0.50)
13.0 (0.51) 0.3 (0.01) 375.9 (14.80) 474.3 (18.67) 487.0 (19.17)
474.0 (18.66) 486.6 (19.16)
808.4 (31.83)
973.5 (38.33)
1120.6 (44.12)
1590.6 (62.62)
1563.6 (61.56)
1855.8 (61.56)
15.9 (0.63) dia.
for Lifting, 2 Places
M8 x 1.25
Captive Mounting
Fastner, 10 Places
Captive Duct
Interface
Hardware,
4 Places
1513.6 (59.59)
1654.6 (65.14)
1718.6 (67.66)
1846.6 (72.70)
1922.6 (75.69)
2012.4 (79.23)
1983.8 (78.10)
2063.7 (81.25)
1248.7 (49.16)
W/T3
V/T2
U/T1
-DC
+DC
T/L3
S/L2
R/L1
DC
(+)
DC
(-)
U/
T1
V/
T2
W/
T3
DC+DC-
TESTPOINTS
DC (+
DC (-
DC (-
DC (+
0.0 (0.00) 0.0 (0.00)
288.4 (11.36) 195.4 (7.69) 0.4 (0.02)
12.5 (0.49)
9.5 (0.38)
12.0 (0.47) x
16.0 (0.63)
60.0
(2.36)
28.6
(1.13)
R/L1, S/L2, T/L3
11.0 (0.43) x
17.0 (0.67)
+DC, -DC
6.4 (0.25)
88.9
(3.50)
30.0
(1.18)
11.8 (0.46)
11.0 (0.43) x
17.0 (0.67)
U/T1, V/T2, W/T3
9.5 (0.38)
57.2
(2.25)
30.0
(1.18)
12.0 (0.47)
Dimensions are in millimeters and (inches)
Height without
Outlet Ducting Kit
Outlet
Ducting Kit
Front View
Left Side View
Height with
Outlet Ducting Kit
