Rockwell Automation Publication 750-IN020D-EN-P - May 2017 27
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Derating Guidelines for Horizontal Mounting - Three-Phase Input/Output, Frame 8 Only
Catalog
Code
Light Duty Normal Duty Heavy Duty
50/60 Hz Input Output 50/60 Hz Input Output 50/60 Hz Input Output
Volts Amps Volts Amps Power Volts Amps Volts Amps Power Volts Amps Volts Amps Power
380…400V AC Three-Phase Input, 2 kHz Carrier Frequency
C460 400 450 0…400 439 200 kW 400 450 0…400 439 200 kW 400 321 0…400 313 160 kW
C540 400 488 0…400 475 224 kW 400 488 0…400 475 224 kW 400 381 0…400 371 200 kW
C567 400 511 0…400 497 250 kW 400 511 0…400 497 250 kW 400 394 0…400 384 200 kW
C650 400 625 0…400 609 315 kW 400 625 0…400 609 315 kW 400 450 0…400 439 224 kW
C750 400 665 0…400 647 355 kW 400 665 0…400 647 355 kW 400 488 0…400 475 250 kW
C770 400 694 0…400 676 355 kW 400 694 0…400 676 355 kW 400 536 0…400 522 300 kW
480V AC Three-Phase Input, 2 kHz Carrier Frequency
D430 480 387 0…460 394 300 Hp 480 387 0…460 394 300 Hp 480 295 0…460 301 200 Hp
D485 480 435 0…460 443 350 Hp 480 435 0…460 443 350 Hp 480 330 0…460 336 250 Hp
D545 480 470 0…460 479 400 Hp 480 470 0…460 479 400 Hp 480 362 0…460 369 250 Hp
D617 480 567 0…460 577 450 Hp 480 567 0…460 577 450 Hp 480 387 0…460 394 300 Hp
D710 480 610 0…460 622 500 Hp 480 610 0…460 622 500 Hp 480 435 0…460 443 350 Hp
D740 480 639 0…460 650 550 Hp 480 639 0…460 650 550 Hp 480 492 0…460 501 400 Hp
600V AC Three-Phase Input, 2 kHz Carrier Frequency
E295 600 272 0…600 288 250 Hp 600 272 0…600 288 250 Hp 600 208 0…600 220 200 Hp
E355 600 302 0…600 320 300 Hp 600 302 0…600 320 300 Hp 600 226 0…600 239 200 Hp
E395 600 332 0…600 352 350 Hp 600 332 0…600 352 350 Hp 600 251 0…600 266 250 Hp
E435 600 352 0…600 373 350 Hp 600 352 0…600 373 350 Hp 600 272 0…600 288 250 Hp
E460 600 390 0…600 413 400 Hp 600 390 0…600 413 400 Hp 600 302 0…600 320 300 Hp
E510 600 416 0…600 441 450 Hp 600 416 0…600 441 450 Hp 600 325 0…600 344 350 Hp
690V AC Three-Phase Input, 2 kHz Carrier Frequency
F265 690 252 0…690 267 250 kW 690 252 0…690 267 250 kW 690 164 0…690 174 186 kW
F330 690 283 0…690 300 300 kW 690 283 0…690 300 300 kW 690 203 0…690 215 200 kW
F370 690 313 0…690 332 335 kW 690 313 0…690 332 335 kW 690 235 0…690 249 250 kW
F415 690 351 0…690 373 375 kW 690 351 0…690 373 375 kW 690 283 0…690 300 300 kW
F460 690 382 0…690 405 400 kW 690 382 0…690 405 400 kW 690 286 0…690 304 315 kW
F500 690 404 0…690 429 425 kW 690 404 0…690 429 425 kW 690 316 0…690 335 350 kW
