34 Rockwell Automation Publication 750-IN020D-EN-P - May 2017
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Figure 16 - Overall Dimensions with Mounting and Termination Kits – Frame 10 AC Input
2377.9
(93.62)
0.0 (0.00)
1228.3 (48.36)
1728.6 (68.05)
1600.6 (63.02)
1472.6 (57.98)
1100.0 (43.31)
953.1 (37.52)
788.0 (31.02)
623.0 (24.53)
2035.2
(80.13)
2065.6
(81.32)
2111.8
(83.14)
2145.0
(84.45)
0.0 (0.00)
119.2 (4.69)
236.2 (9.30)
466.0 (18.35)
1666.5 (53.80)
1978.8 (77.91)
157.0
(6.18)
309.9
(12.20)
420.5
(16.56)
1577.8
(62.12)
777.9
(30.63)
Dimensions are in millimeters and (inches)
Front View Right Side View
5 mm Hex Key (Allen) 10 places/bay
11.3 N•m (100 lb•in)
5.0 mm (0.2 in.) - 4 places/bay
11.3 N•m (100 lb•in)
