Allen-Bradley PowerFlex 755 IP00 User Manual

Rockwell Automation Publication 750-IN020D-EN-P - May 2017 35
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Figure 17 - Overall Dimensions with Mounting and Termination Kits–Frame 10 Common DC Input
0.0 (0.00)
1228.3 (48.36)
1100.0 (43.31)
953.1 (37.52) 788.0 (31.02) 623.0 (24.53)
2377.9
(93.62)
1577.8
(62.12)
777.9
(30.63)
0.0 (0.00)
119.2 (4.69)
236.2 (9.30)
466.0 (18.35)
1666.5 (53.80) 1978.8 (77.91)
157.0
(6.18)
309.9
(12.20)
420.5
(16.56)
2035.2
(80.13)
2145.0
(84.45)
2111.8
(83.14)
Dimensions are in millimeters and (inches)
Front View Right Side View
5 mm Hex Key (Allen) 10 places/bay 11.3 N•m (100 lb•in)
5.0 mm (0.2 in.) - 4 places/bay 11.3 N•m (100 lb•in)
