140 Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017
Appendix D EtherNet/IP Objects
For more information regarding PCCC commands, see the DF1
Protocol and Command Set Reference Manual, publication 1770-
6.5.16.
0x0F 0xA9 SLC 500 protected typed write with 2 address fields
0x0F 0x00 Word range read
0x0F 0x01 Word range write
Table 41 - PCCC Object: EtherNet/IP Interface Supports (continued)
CMD FNC Description
Table 42 - N-File Descriptions (All N-files are 16-Bit integers)
N-File Description
N42 This N-file lets you read and write some values configuring the port.
N42:3 Time-out (read/write): Time (in seconds) allowed between messages to the N45 file. If the interface does not receive a
message in the specified time, it performs the fault action configured in its [Comm Flt Action] parameter. A valid
setting is 1...32767 seconds (5…20 seconds is recommended).
N42:7 Interface Port Number (read only): Drive port in which the interface resides.
N42:8 Peer interface (read only): Bit field of devices with peer messaging capabilities.
N45 This N-file lets you read and write control I/O messages. You can write control I/O messages only when the following
conditions are true:
The interface is not receiving /O from a controller. For example, there is no controller on the network, the controller is
in idle (program) mode, the controller is faulted, or the interface is not mapped to the controller.
The value of N42:3 is set to a nonzero value.
Write Read
N45:0 Logic Command (least significant) Logic Command (least significant)
N45:1 Logic Command (most significant) Logic Command (most significant)
N45:2 Reference (least significant) Feedback (least significant)
N45:3 Reference (most significant) Feedback (most significant)
N45:4 DL From Net 01 (least significant) DL To Net 01 (least significant)
N45:5 DL From Net 01 (most significant) DL To Net 01 (most significant)
N45:6 DL From Net 02 (least significant) DL To Net 02 (least significant)
N45:7 DL From Net 02 (most significant) DL To Net 02 (most significant)
N45:8 DL From Net 03 (least significant) DL To Net 03 (least significant)
N45:9 DL From Net 03 (most significant) DL To Net 03 (most significant)
N45:10 DL From Net 04 (least significant) DL To Net 04 (least significant)
N45:11 DL From Net 04 (most significant) DL To Net 04 (most significant)
N45:12 DL From Net 05 (least significant) DL To Net 05 (least significant)
N45:13 DL From Net 05 (most significant) DL To Net 05 (most significant)
N45:14 DL From Net 06 (least significant) DL To Net 06 (least significant)
N45:15 DL From Net 06 (most significant) DL To Net 06 (most significant)
N45:16 DL From Net 07 (least significant) DL To Net 07 (least significant)
N45:17 DL From Net 07 (most significant) DL To Net 07 (most significant)
To Next Page
