32 Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017
Chapter 2 Configure the Interface
After verifying correct operation, place the drive HIM bezel to its closed
position and install the drive cover. For more details on status indicator
operation, see page 118
.
Table 1 - Drive and Interface Start-up Status Indications
Item Name Color State Description
Drive STS Indicator
1 STS (Status) Green Flashing Drive ready but is not running, and no faults are present.
Steady Drive is running and no faults are present.
Yellow Flashing When running, a type 2 (non-configurable) alarm condition exists – the drive
continues to run. When stopped, a start inhibit condition exists and the drive
cannot be started (see drive 0:603 - [Start Inhibit]).
Steady A type 1 (configurable) alarm condition exists, but the drive continues to run.
Red Flashing A major fault has occurred. The drive stops. it cannot be started until the fault
condition is cleared.
Steady A non-resettable fault has occurred.
Red/Yellow Flashing
Alternately
A minor fault has occurred. If not enabled a minor fault, acts like a major fault. If
minor faults are enabled and the drive is running, the drive continues to run. The
system is brought to a stop under system control. The fault must be cleared to
continue.
Yellow/
Green
Flashing
Alternately
When running, a type 1 (configurable) alarm exists and the drive continues to
run.
Green/Red Flashing
Alternately
The drive is updating firmware.
Built-in EtherNet/IP interface Status Indicators
2 ENET Unlit Off The interface and/or network is not powered, the interface is not properly
connected to the network, or the interface needs an IP address.
Red Flashing A network connection has timed out, the rotary switches have been changed
since power-up, or the network configuration is invalid.
Steady The interface failed the duplicate IP address detection test or its DCHP lease has
expired.
Red/Green Flashing
Alternately
The interface is performing a self-test.
Green Flashing The interface is properly connected, but the drive is not controlled by the
network.
Steady The interface is properly connected, and the drive is controlled by the network.
3LNK1 and
LNK2
Unlit Off The interface does not have an Ethernet link.
Green
(100 Mbps)
or
Yellow
(10 Mbps)
Flashing The interface is properly connected and is transmitting or receiving data packets
on the network.
Steady The interface is properly connected, but is not transmitting or receiving on the
network.
