Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017 101
Using Explicit Messaging Chapter 5
Ladder Logic Program to Write a Single Parameter
A Set Attribute Single message is used to write to a parameter. This write
message example writes a value to the 32-bit REAL (floating point) 10: 1915 -
[VRef Accel Time 1] in a PowerFlex 755T drive.
Table 11 - Example Controller Tags to Write a Single Parameter
Figure 21 - Example Ladder Logic to Write a Single Parameter
Operand Controller Tags for Single Write Message Data Type
XIC Execute_Single_Write_Message BOOL
MSG Single_Write_Message MESSAGE
