Rockwell Automation Publication 750COM-UM009A-EN-P - May 2017 89
Using the I/O Chapter 4
Tab le 6 shows the I/O image when using all 32-bit datalinks.
Using Logic Command/Status
The controller produces the logic command, a 32-bit word of control data,
which is used by the drive or bus supply. The drive or bus supply produces logic
status, a 32-bit word of status data, which is used by the controller.
When using a ControlLogix controller with the drive Add-on Profile, the logic
command word is always DINT 0 in the output image. The logic status word is
always DINT 0 in the input image.
This manual contains the bit definitions for compatible products available at
the time of publication in Appendix E
, Logic Command/Status Words:
PowerFlex 755T drives and Bus Supplies.
Using Reference/Feedback
The controller produces the reference, a 32-bit REAL (floating point) word of
control data that is used by the PowerFlex drives 755TL, 755TR, or 755TM
common bus inverter. The drive or bus supply produces feedback, a 32-bit
REAL (floating point) word of status data, which is used by the controller.
Table 6 - ControlLogix I/O Image for PowerFlex 755T Drives
(32-bit Logic Command/Status, Reference/Feedback, and Datalinks)
DINT Output (Controller to Drive) I/O DINT Input (Drive to Controller) I/O
0Logic Command 0Logic Status
1 Reference 1 Feedback
2 DL From Net 01 2 DL To Net 01
3 DL From Net 02 3 DL To Net 02
4 DL From Net 03 4 DL To Net 03
5 DL From Net 04 5 DL To Net 04
6 DL From Net 05 6 DL To Net 05
7 DL From Net 06 7 DL To Net 06
8 DL From Net 07 8 DL To Net 07
9 DL From Net 08 9 DL To Net 08
10 DL From Net 09 10 DL To Net 09
11 DL From Net 10 11 DL To Net 10
12 DL From Net 11 12 DL To Net 11
13 DL From Net 12 13 DL To Net 12
14 DL From Net 13 14 DL To Net 13
15 DL From Net 14 15 DL To Net 14
16 DL From Net 15 16 DL To Net 15
17 DL From Net 16 17 DL To Net 16
