Appendix A PowerMonitor 500 Unit Data Tables
Total and Partial Energy Meters - EtherNet/IP Data Table
Table 23 - Table Properties
CIP Assembly Instance 107
No. of Elements 18
Length in Words 36
Data Type REAL
Data Access Read Only
Table 24 - Total and Partial Energy Meters - EtherNet/IP Data Table
Element Length
(words)
Description / Units Data Format Notes
0 2 Total kWh+ REAL Range 0.0 … 999,999.999
1 2 Total GWh+ REAL Range 0 … 9,999,999
2 2 Total kVARh+ REAL Range 0.0 … 999,999.999
3 2 Total GVARh+ REAL Range 0 … 9,999,999
4 2 Total kWh- REAL Range 0.0 … 999,999.999
5 2 Total GWh- REAL Range 0 … 9,999,999
6 2 Total kVARh- REAL Range 0.0 … 999,999.999
7 2 Total GVARh- REAL Range 0 … 9,999,999
8 2 Partial kWh+ REAL Range 0.0 … 999,999.999
9 2 Partial GWh+ REAL Range 0 … 9,999,999
10 2 Partial kVARh+ REAL Range 0.0 … 999,999.999
11 2 Partial GVARh+ REAL Range 0 … 9,999,999
12 2 Partial kWh- REAL Range 0.0 … 999,999.999
13 2 Partial GWh- REAL Range 0 … 9,999,999
14 2 Partial kVARh- REAL Range 0.0 … 999,999.999
15 2 Partial kVARh- REAL Range 0 … 9,999,999
16 2 Hours counter REAL
17 2 Minutes counter REAL Range 0 … 59
