Allen-Bradley PowerMonitor 500

72 Rockwell Automation Publication 1420-UM001E-EN-P - March 2016
Appendix B Technical Specifications
List of Connectable Variables
The variables that are listed in this table can be connected to the following items:
• Analog outputs (all variables except energy values and run hour counter)
• Pulse (digital relay)outputs (only energy values)
• Alarms (except energy, hour counter, and max values)
(X) = available; (O) = not available (variable not available on the display);
(#) Not available (the relevant page is not displayed); (1) Max value with data
storage
Table 45 - Variables
No Variable 1-ph. Sys (1P) 2-ph. Sys (2P) 3-ph. 3/4-wire
Balanced Sys
(3P.1)
3-ph. 2-wire
Balanced Sys
(3P.2)
3-ph. 3-wire
Unbal. Sys (3P)
3-ph. 4-wire
Unbal. Sys
(3P.n)
Notes
1 VL-N sys O X X X # X sys= system=  (1)
2 VL1 X X X X # X (1)
3 VL2 O X X X # X (1)
4VL3 O O X X # X (1)
5 VL-L sys O X X X X X sys= system= (1)
6 VL1-2 # X X X X X (1)
7VL2-3 # O X X X X (1)
8 VL3-1 # O X X X X (1)
9 AL1 X X X X X X (1)
10 AL2 O X X X X X (1)
11 AL3 O O X X X X (1)
12 VA sys X X X X X X sys= system=  (1)
13 VA L1 X X X X # X (1)
14VA L2OXXX # X(1)
15 VA L3 O O X X # X (1)
16 var sys X X X X X X sys= system=  (1)
17 var L1 X X X X # X (1)
18 var L2 O X X X # X (1)
19 var L3 O O X X # X (1)
20 W sys X XXXXXsys= system=  (1)
21 WL1 X X X X # X (1)
22 WL2 O X X X # X (1)
23 WL3 O O X X # X (1)
24 PF sys X X X X X X sys= system=  (1)
25 PF L1XXXX# X (1)
26 PF L2 O X X X # X (1)
27PF L3OOXX# X (1)
28 Hz X X X X X X (1)
29 Phase seq.OXXXXX
30Run Hours XXX X XX
31kWh (+) X X XXXXTotal
