Allen-Bradley PV300 Micro User Manual

Publication 2711-UM014B-EN-P
Terminal Overview 1-5
PanelView 900 Monochrome Terminals
These terminals are no longer available for purchase.
1
Add L1 to the end of the catalog number for 24V dc power.
PanelView 900 Color Terminals
1
Add L1 to the end of the catalog number for 24V dc power.
Operator
Input
Communication Port
Printer Port
RS-232
Catalog
Number
1
RIO DH-485 RS-232
(DH-485)
DH+ DeviceNet ControlNet RS-232
(DF1)
Touch
Screen
x x 2711-T9A1
x 2711-T9A2
xx2711-T9A3
x 2711-T9A5
xx2711-T9A8
xx2711-T9A9
xx2711-T9A10
xx2711-T9A15
xx 2711-T9A16
Keypad
x x 2711-K9A1
x 2711-K9A2
xx2711-K9A3
x 2711-K9A5
xx2711-K9A8
xx2711-K9A9
xx2711-K9A10
xx2711-K9A15
xx 2711-K9A16
Operator
Input
Communication Port
Printer Port
RS-232
Catalog
Number
1
RIO DH-485 RS-232
(DH-485)
DH+ DeviceNet ControlNet RS-232
(DF1)
Ethernet
Touch
Screen
x x 2711-T9C1
x x 2711-T9C3
xx2711-T9C8
xx2711-T9C9
xx2711-T9C10
xx2711-T9C15
xx2711-T9C16
xx2711-T9C20
Keypad
x x 2711-K9C1
x x 2711-K9C3
xx2711-K9C8
xx2711-K9C9
xx2711-K9C10
xx2711-K9C15
xx2711-K9C16
xx2711-K9C20
