Allen-Bradley PV300 Micro User Manual

Publication 2711-UM014B-EN-P
Terminal Connections 12-3
Note 1: AIC + Module recommended for isolation purposes when PanelView and controller are not on same power
supply
Cables: PanelView to Processor
Protocol PanelView Standard Comm Port
PLC-5, PLC-5C, PLC-5E
CH0 (25-pin RS-232)
(DF1)
ControlLogix
CH0 (9-pin RS-232)
(DF1)
MicroLogix 1000, 1200,
1500LSP
CH0 (8-pin Mini DIN)
(DF1 or DH-485)
DF1
xxx16
xxx17
xxx18
RS-232 (DF1) Comm Port (8-pin Mini Din)
PanelView 300 Micro
2711-xxx18
1761-CBL-AP00 (1.5ft/0.5m)
1761-CBL-PM02 (6.5ft/2m)
2711-CBL-PM05 (16ft/5m)
2711-CBL-PM10 (32ft/10m)
(9-to-25 pin adapter required)
1761-CBL-AP00 (1.5ft/0.5m)
1761-CBL-PM02 (6.5ft/2m)
2711-CBL-PM05 (16ft/5m)
2711-CBL-PM10 (32ft/10m)
1761-CBL-AM00 (1.5ft/0.5m)
1761-CBL-HM02 (6.5ft/2m)
2711-CBL-HM05 (16ft/5m)
2711-CBL-HM10 (32ft/10m)
** See Note 1 **
RS-232 (DF1) Communication Port (9-pin)
PanelView 300 - 1400
2711-xxx16, 2711-xxx17
2711-NC13 (16ft/5m)
2711-NC14 (32ft/10m)
2706-NC13 (10ft/3m)
(9-to-25 pin adapter required)
2711-NC13 (16ft/5m)
2711-NC14 (32ft/10m)
2706-NC13 (10ft/3m)
2711-NC21 (16ft/5m)
2711-NC22 (49ft/15m)
(null modem not required)
** See Note 1 **
DH-485
xxx2
xxx3
xxx5
xxx9
xxx19
RS-232 (DH-485) Comm Port (8-pin Mini Din)
PanelView 300 Micro
2711-xxx19
N/A N/A 1761-CBL-AM00 (1.5ft/0.5m)
1761-CBL-HM02 (6.5ft/2m)
2711-CBL-HM05 (16ft/5m)
2711-CBL-HM10 (32ft/10m)
** See Note 1 **
RS-232 (DH-485) Communication Port (9-pin)
PanelView 300 - 1400
2711-xxx5, 2711-xxx9
N/A N/A 2711-NC21 (16ft/5m)
2711-NC22 (49ft/15m)
(null modem not required)
** See Note 1 **
DH-485 Communication Port (RJ45)
PanelView 300 - 1400
2711-xxx2, 2711-xxx3
N/A N/A use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
DeviceNet
xxx10
DeviceNet Communication Port
PanelView 300 - 1400
2711-xxx10
use 1771-SDN Module
with
DeviceNet cable
use 1756-DNB Module
with
DeviceNet cable
use 1761-NET-DNI Module
with DeviceNet cable
ControlNet
xxx15
ControlNet Communication Port
PanelView 550T - 1400
2711-xxx15
to PLC-5C
with
ControlNet cable
use 1756-CNB Module
with
ControlNet cable
N/A
EtherNet/IP
xxx20
Ethernet Communication Port
PanelView 550T - 1400
2711-xxx20
to PLC-5E
with
Ethernet cable
Use 1756-ENET Module
with
Ethernet cable
Use 1761-NET-ENI Module with
Ethernet cable
Remote I/O
xxx1
Remote I/O Communication Port
PanelView 550T - 1400
2711-xxx1
shielded twinaxial cable
(1770-CD)
use 1756-DHRIO Module
with
shielded twinaxial cable
(1770-CD)
N/A
DH+
xxx8
DH+ Communication Port
PanelView 550T - 1400
2711-xxx8
shielded twinaxial cable
(1770-CD)
use 1756-DHRIO Module
with
shielded twinaxial cable
(1770-CD)
N/A
