Publication 2711-UM014B-EN-P
Terminal Connections 12-11
Typical DH+ System Configuration
For more information on the Allen-Bradley DH+ link, refer to:
• 1785-5.7 Enhanced PLC-5 Programmable Controllers Installation
Instructions
• 1770-6.2.2 Data Highway/Data Highway Plus/Data Highway II/
Data Highway 485 Cable Installation Manual.
DH+ Port
DH+ Port
RS-232 Port
Computer for developing
PanelView applications
DH+ RSLinx Port
DH+ communication card
installed in computer
Download applications to PanelView
1 over local DH+ link
2 over a direct serial link
PanelView 600 DH+ Terminal
PanelView 1000 DH+ Terminal
SLC 5/04
PLC-5
1
1
2 Serial Link
To Next Page
