A-2 Specifications
Character Sizes (Pixel size = 0.48 x 0.48 mm)
PanelView 300
Size in Pixels
width x height)
Characters/Row Maximum Rows
Dimensions in mm
Width x Height
4 x 6 31
10
1.9 x 2.9
6 x 8 20
7
2.9 x 3.8
6 x 16 20
3
2.9 x 7.7
6 x 24 20
2
2.9 x 11.5
12 x 8 10
7
5.8 x 3.8
12 x 16 10
3
5.8 x 7.7
12 x 24 10
2
5.8 x 11.5
18 x 8 6
7
8.6 x 3.8
18 x 16 6
3
8.6 x 7.7
18 x 24 6
2
8.6 x 11.5
Electrical
DC Power
Supply Voltage Limits
Power Consumption
18 to 32V dc (24V dc nominal)
10 Watts, max. (0.42A @ 24V dc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only), IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight 673 grams (1.48 lbs)
Dimensions
mm
Inches
197 (H) x 140 (W) x 82 (D)
7.76 (H) x 5.53 (W) x 3.21 (D)
Installed Depth 69mm (2.73 inches)
122.4 mm (4.82 inches) with memory card
retainer
216 mm (8.5 inches) with memory card retainer
and clearance to insert and remove memory card
Display
Type Liquid Crystal Display (LCD) with integral LED
backlight (100,000 hour life)
Size 73 mm (w) x 42 mm (h)
2.87 in. (w) x 1.67 in. (h)
Pixels 128 x 64
