Allen-Bradley PV300 Micro User Manual

Publication 2711-UM014B-EN-P
Specifications A-9
PanelView 900
Monochrome and Color
Electrical
AC Power - PV900M and PV900C
Supply Voltage Limits
Power Consumption
85 to 264V ac, 47 to 63 Hz
110 VA maximum
DC Power - PV900M
Supply Voltage Limits
Power Consumption
DC Power - PV900C
Supply Voltage Limits
Power Consumption
18 to 30 V dc (24V dc nominal)
58 Watts max. (2.5A @ 24V dc)
18 to 32 V dc (24V dc nominal)
50 Watts max. (2.1A @ 24V dc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only) IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight - PV900M
Keypad
Touch Screen
3.14 kg (4.4 lbs)
2.91 kg (6.4 lbs)
Weight - PV900C
Keypad
Touch Screen
3.18 kg (7.0 lbs)
2.95 kg (6.5 lbs)
Dimensions - PV900M/900C Keypad
mm
inches
249 (H) x 406 (W) x 112 (D)
9.80 (H) x 15.97 (W) x 4.40 (D)
Dimensions - PV900M/900C Touch Screen
mm
inches
249 (H) x 336 (W) x 112 (D)
9.80 (H) x 13.24 (W) x 4.40 (D)
Installed Depth - PV900M 97 mm (3.81 inches)
129 mm (5.06 inches) with memory card retainer
220 mm (8.65 inches) with memory card retainer
and clearance to insert and remove memory card
Installed Depth - PV900C 99 mm (3.89 inches)
131 mm (5.14 inches) with memory card retainer
222 mm (8.73 inches) with memory card retainer
and clearance to insert and remove memory card
