PanelView 300 Screen Setup
Contrast
Increases or decreases the display contrast. The contrast settings range
from 0 to 10.
Video Mode
Toggles between normal video (dark text/graphics on a light
background) and reverse video (light text/graphics on a dark
background). Changes take effect immediately.
Reset Video
Resets the display to normal (default settings). The [F3] key is also
active on the Configuration Mode menu. If the screen is set to a
non-viewable setting, press the Left and Right arrow keys
simultaneously. Then press [F3] to reset the screen.
Screen Saver Mode
Mode - Select Timed or Off screen saver. When Timed, the screen
intensity is reduced if user input or a controller screen change is not
received within the time specified in the Screen Saver Timeout
Timeout
Specifies when an inactive screen enters screen saver mode. The
timeout is adjusted in steps with each key press: 5, 10, 15, 20, 25, or
30 minutes.
Exit
Returns to the Configuration Mode menu.
SCREEN SETUP
F1 Contrast
F8 EXIT
6
F7 MORE
F2 Mode
Normal
F3 Reset Video
SCREEN SAVER
F1 Mode
F8 EXIT
Off
F7 MORE
F2 Timeout
10 min.
IMPORTANT
Certain settings may make viewing the screen
difficult. Do not exit this screen until viewing
adjustments are acceptable.
