Rockwell Automation Publication 150-QS003E-EN-P - April 2017 35
Appendix A
SCCR Ratings
SCCR Ratings
Table 17 - SCCR (High Capacity Fault) Electrical Ratings for Integrated Bypass Units
Type 1 Coordination
(1)
SCPD Performance
(2)
Class J or Class L Fuse
(3)
Inverse Time (Thermal Magnetic) Circuit Breaker
(4)
Motor Connection
Type
Cat. No.
Current
Rating
[A]
Maximum
Available Fault
(600V) [kA]
Max. Current [A]
480V, 65 kA Maximum
Bul. 140G
Frame
Size
Max.
Current
[A]
Cat. No. Rating Plug
Line
150-S108N… 108
70
200
Pending
(5)
150-S135N… 135 225
150-S201N… 201 350
150-S251N… 251 400
150-S317N.… 317
69
500
150-S361N… 361 600
150-S480N… 480 800
Inside-the-Delta
150-S108N… 187
70
300
150-S135N… 234 400
150-S201N… 348 600
150-S251N… 435 800
150-S317N… 549
69
1000
150-S361N… 625 1200
150-S480N… 831 1600
(1) Basic Requirements for Type 1 Coordination: Under the short-circuit condition, the starter shall cause no danger to persons or the installation. The starter may not be suitable for further service
without repair or replacement of parts. For further details, See UL508/CSA C22.2 No. 14 and EN 60947-4-2.
(2) Consult local codes for proper sizing of short-circuit protection.
(3) High capacity fault ratings when used with a time delay Class J fuse or time delay Class L fuse.
(4) Circuit Breaker must be of the designated 140G Frame size.
(5) Other circuit breakers pending.
