Alliance Laundry Systems BA025E - Page 22

U Models
TMB1785R_SVG
1
2
3
4
5
6
7
8
1. Display
2. 7-segment Digits
3. Increase/Decrease COOL DOWN TIME
4. START (enter) Keypad
5. REVERSING Keypad
6. DISPLAY Keypad
7. SELECT Temperature Keypad
8. Increase/Decrease HEAT TIME
B Models
TMB1786R_SVG
1
2
3
4
5
6
7
8
1. Display
2. 7-segment Digits
3. Increase/Decrease COOL DOWN TIME
4. START (enter) Keypad
5. REVERSING Keypad
6. DISPLAY Keypad
7. SELECT Temperature Keypad
8. Increase/Decrease HEAT TIME
P Models
TMB1787R_SVG
1
2
3
4
5
6
7
8
1. Display
2. 7-segment Digits
3. Increase/Decrease COOL DOWN TIME
4. START (enter) Keypad
5. REVERSING Keypad
6. DISPLAY Keypad
7. SELECT Temperature Keypad
8. Increase/Decrease HEAT TIME
N Models
TMB1788R_SVG
1
2
3
4
5
6
7
8
1. Display
2. 7-segment Digits
3. Increase/Decrease COOL DOWN TIME
4. START (enter) Keypad
5. REVERSING Keypad
6. DISPLAY Keypad
7. SELECT Temperature Keypad
8. Increase/Decrease HEAT TIME
Control Identification
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
22 Part No. 70579901ENR9
