Machine Diagnostic Functions
Manual Diagnostic Mode Menu
The Manual Diagnostic Mode allows an operator to run diagnos-
tic tests on various machine operations (refer to Table 3 ) without
servicing the machine.
1. From Manual Mode (refer to How to Enter Manual Program-
ming Mode), select di Ag and press the START (enter) key-
pad.
2. Press the SELECT (∧) or DISPLAY (∨) keypads to scroll
through the diagnostic test options until the desired option is
displayed.
3. Press the START (enter) keypad to select the desired option.
4. Press the SELECT (∧) or DISPLAY (∨) keypads to scroll
through the diagnostic test option steps.
5. Press the START (enter) keypad to run the diagnostic test.
NOTE: Press the SELECT (∧) and DISPLAY (∨) keypads
at the same time to cancel a diagnostic test before it is
complete.
6. To exit the Manual Diagnostic Mode, simultaneously press
the SELECT (∧) and DISPLAY (∨) keypads to return to the
Manual Mode menu.
Diagnostic (Testing) Mode – Quick
Reference
Test Number Diagnostic Mode Display
d 01
Front-End Control Software Version Num-
ber
SX XX, XX
d 02
Input/Output Board Software Version
Number
ob XX, XX
d 03
Drive Board Software Version Number
db XX
d 04
Fan Board Software Version Number
(Tumble Dryer Designs 3 and 5, Stacked
Washer-Extractor/Tumble Dryer Designs 1
and 2)
Fb XX
d 05
Ignition Control Software Version Number
(gas models only)
iC XX
d 08
Service Door Switch Input Test
S oP, S CL
d 14 *
Dryer On Temp Test
XX XF or XX XC, NN
d 15 *
Door Switch Input Test
dr oP, dr CL
d 16 *
Lint Door Switch Input Test
Lt oP, Lt CL
d 19
Temperature Sensor Display Test
XX XF or XX XC, SH, oP
d 20
12.5VDC Voltage Test
XX XX
d 21
24VDC Voltage Test
XX XX
d 28
AC Mains Voltage Test
X XX
d 29
Machine Configuration #1 Display Test
AX XX
d 30
Machine Configuration #2 Display Test
bX XX
d 31
Machine Configuration #3 Display Test
CX XX
d 32
Machine Configuration #4 Display Test
dX XX
Table 3 continues...
