Factory Test Cycle
The Factory Test Cycle allows the user to view machine details
and run the machine through various cycle steps. Refer to Table
8 . The control enters Machine Error Mode if any fatal errors oc-
cur during the test cycle.
1. While in Start Mode, simultaneously press the SELECT (∧)
and START (enter) keypads.
2. When the control enters Factory Test, it displays the first test
step, Machine Type.
3. The control advances through the sequence of test steps when
START (enter) is pressed, with the exception of the Keypad
Test and Pressure Sensor Test. Refer to Factory Test Quick
Reference Chart for all steps in the Factory Test.
4. Disconnect then reconnect the electrical power to the machine
to exit a test cycle.
NOTE: If the control is powered down during a test
cycle, the control will begin in the Start Mode when
power is restored.
Factory Test Quick Reference Chart
Factory Test Cycles
Display Test Mode Comments
td
Machine Type
td is the machine type (tumble dryer).
SXXX
Software Version
XXX is the software version number.
XX (skipped if 0)
Software Subversion
XX is the software subversion.
obXX
Output Board Version Number
XX is the output board version number.
XX (skipped if 0)
Output Board Subversion Number
XX is the output board subversion number.
dbXX
Drive Software Version Number
XX is the drive software version number.
FbXX (Tumble Dryer Designs 3 and 5,
Stacked Washer-Extractor/Tumble Dryer
Designs 1 and 2)
Fan Drive Software Version Number
XX is the fan drive software version num-
ber.
icXX (skipped if electric or steam ma-
chine)
ICM Software Version
XX is the ICM software version number.
XX XX
DipSwitch Configuration
XX is the machine type. 00 is 120V and
01 is 240V.
X XX
Machine Size
XXX is the configured machine size. tXX
is for stack machines and FXX is for fast
dry.
Pad or PAXX
Keypad Test When a key is pressed, the control will
display the number assigned to the keypad
(1 - COOL DOWN -, 2 - COOL DOWN
+, 3 - HEAT -, 4 - HEAT +, 5 - START, 6 -
REVERSING, 7 - DISPLAY, 8 - SE-
LECT). As each keypad is pressed, its cor-
responding LED will be lit and remain on
for the duration of the test. When all key-
pads have been pressed, the control will
advance to Show Entire Display Mode test
cycle.
Table 8 continues...
Factory Test Cycle
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
48 Part No. 70579901ENR9
