Factory Test Cycles
Display Test Mode Comments
All LEDs and display segments will light Show Entire Display Mode This mode will light all display elements
and sound the audio.
S oP or S CL
Service Door Switch Test
oP signifies the service door switch is
open or CL signifies the service door
switch is closed.
dr oP or dr CL
Loading Door Test
oP signifies the loading door is open or CL
signifies the loading door is closed.
Lt oP or Lt CL
Lint Door Test
oP signifies the lint door is open or CL
signifies the lint door is closed.
XX XF or XX XC
Thermistor Temperature Test The temperature will be displayed in either
Fahrenheit or Celsius, depending on ma-
chine’s configuration (refer to Temperature
(Fahrenheit/Celsius) tP F C). If control
senses a shorted thermistor, SH will be dis-
played. If control senses an open thermis-
tor, oP will be displayed.
PU SH, St rt, 09 01, do or
10 Minute Test Cycle Determines if dryer can function in a cycle
for 10 minutes. LED display will flash one
second on and one second off. If the door
is opened while the START LED is flash-
ing, the control will display door until the
door is closed. While this 10 Minute Test
Cycle is running, the START pad may be
used to decrement the remaining cycle
time. If power to the control is turned off
before this test cycle has ended, the cycle
is cleared. When the control is powered
back up, it will be reset to Ready Mode.
Pd
Power Down This is the final step of the Factory Test
Cycle and when displayed it signifies the
test has been completed.
Table 8
NOTE: If power to the control is turned off before 10 Mi-
nute Test Cycle has ended, the cycle will be cleared
from control.
Factory Test Cycle
©
