Configuration Value
Dipswitch 8
(Heat Source)
Dipswitch 7
(Heat Source)
Dipswitch 6
(Reserved)
Dipswitch 5
(Unused)
Dipswitch 4
(Temp Units)*
Dipswitch 3
(Reserved)
Dipswitch 2
(Extended Tumble)
Dipswitch 1
(Volt Supply)**
252 ON ON ON ON ON ON OFF OFF
253 ON ON ON ON ON ON OFF ON
254 ON ON ON ON ON ON ON OFF
255 ON ON ON ON ON ON ON ON
*OFF = Fahrenheit, ON = Celsius
**OFF = 120 VAC, ON = 240 VAC
Table 6
Machine Configuration #5 Display Test d 33
This option shows the voltage configuration of the machine and
the fan speed type. To start test, control must be in the Manual
Diagnostic Mode Menu.
To enter, press the START (enter) keypad. For configuration val-
ue #5, the display will show EX XX. XXX is a number corre-
sponding to the voltage parameter and fan speed. Refer to Table
7 .
To exit the test, simultaneously press the SELECT (∧) and DIS-
PLAY (∨) keypads. The control will return to the Manual Diag-
nostic Mode Menu.
Config Value
Adjust Fan
Speed for
Heat Type
480V Motor
Drives
2 Gas/Steam OFF
3 Gas/Steam ON
4 Electric OFF
5 Electric ON
6 Eco Gas OFF
7 Eco Gas ON
8 Eco Electric OFF
9 Eco Electric ON
10 Low kW Electric OFF
Table 7 continues...
Config Value
Adjust Fan
Speed for
Heat Type
480V Motor
Drives
11 Low kW Electric ON
Table 7
ICM Alarm Status d 34 (gas models only)
This option shows the status of the ICM (Ignition Control Mod-
ule) Alarm. To start test, control must be in the Manual Diagnos-
tic Mode Menu.
To enter, press the START (enter) keypad. The display will show
A on if the alarm is active for at least one second or Ao FF if
the alarm is not active for one second.
To exit the test, simultaneously press the SELECT (∧) and DIS-
PLAY (∨) keypads. The control will return to the Manual Diag-
nostic Mode Menu.
ICM Reset Test d 35 (gas models only)
The ICM Reset Test can be used to clear/reset an active alarm. To
start test, control must be in the Manual Diagnostic Mode Menu.
When the test is entered, the display will show rS Et. Press the
START (enter) keypad. When this test is started, the ICM reset
will become active. If the reset signal is active for a long enough
period of time (3.5 seconds) the ICM Lockout input will become
inactive (3.5 seconds) and then stop the ICM Reset Test.
To exit the test, simultaneously press the SELECT (∧) and DIS-
PLAY (∨) keypads. The control will return to the Manual Diag-
nostic Mode Menu.
Machine Diagnostic Functions
©
