Specifications and Dimensions
Part No. 70458101ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 23
Steam Outlet
Models Diameter B1 B2 D
200S 1 in. NPT 44.625 in. (1,133 mm) 8.75 in. (222 mm) 71.75 in. (1,822 mm)
Electrical Connection
Models C E
120S 18.34 in. (466 mm) 77.84 in. (1,977 mm)
170S 21 in. (533 mm) 81 in. (2,057 mm)
200S 21 in. (533 mm) 81 in. (2,057 mm)
