Operating Instructions
74
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458101ENR7
General Operation
The Diagnostic Microprocessor Control (DMP) is designed
to manage the drying and cooling cycles of the tumble dryer.
The controller is also programmed from the factory with five
different default programs as described below. The operator
has the flexibility to select the time for the drying and the cool
down cycles and the drying temperature. The operator may also
select either reversing or nonreversing basket action only if the
tumble dryer is equipped for reversing. The operator may also
reprogram the default programs. See Programming.
Programs
Dry
Time
(Min.)
Cool
Time
(Min.)
Temp.
Set Point Reversing
1 – Towels 40 5 185º/195ºF
(85º/91ºC)
No
2 – Sheets 30 5 165ºF
(74ºC)
Yes
3 – Misc-1 30 5 150ºF
(66ºC)
No
4 – Misc-2 25 5 135ºF
(57ºC)
Yes
5 – Extra
Dry
5 2 150ºF
(66ºC)
No
Table 15 Default Programs
NOTE: If an altered program is determined to be
corrupted, the default program settings will be used.
Features
• Drying time: 0-60 minutes
• Cooling time: 2-60 minutes
• LED display of cycle time, set temperature, and actual
temperature
• Thermistor controlled temperature
• Safety tumble cycle
• Buzzer for end of cycle, audible alarm
• Reversing/Nonreversing selection
• Five user programmable programs
• RPM display – when equipped with rotational sensor only
• Monitors the lint door switch operation
• Monitors the thermistor for operation
The minimum drying time is 0 minutes, and the minimum
cooling time is 2 minutes. The maximum drying or cooling time
is 60 minutes. The drying temperature may be set from 100ºF
(38ºC) to 185º/195ºF (85º/91ºC). The drying time, cooling time,
or temperature may be modified during an operating cycle.
If it is necessary to reset the drying and cooling times for the
current cycle, press STOP once to stop the tumble dryer. Press
STOP again to cancel the cycle.
If it is necessary to change programs during a current cycle,
press STOP once to stop the tumble dryer and press STOP again
to cancel the current cycle.
DMP OPL Models
RD Control Suffix
