Alliance Laundry Systems CA120L - Properties of CE Gases

Installation
36
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458101ENR7
Gas
Type
Gas
Family Group
Gas
Designation
Supply
Pressure
in. wc
(mbar, kPa)
Manifold
Pressure
in. wc
(mbar, kPa)
Capacity/
Model
Orifice
Diameter
inch
(mm)
Orifice
Part
Number Quantity
120 0.0980
(2.5)
M406361 3
170 0.1200
(3.0)
M401017 3
G30 14.9/20
(37/50, 3.7/5.0)
12.05
(30, 3.0)
200 0.1220
(3.1)
70070903 3
120 0.0980
(2.5)
M406361 3
170 0.1200
(3.0)
M401017 3
I
3+ / 3P
G30 /
G31
11.25/14.9
(28/37, 2.8/3.7)
Unregulated
200 0.1220
(3.1)
70070903 3
Table 1
Properties of CE Gases
Wi Hi Ws Hs d
Wobbe
Index
(net)
Heating
Value
(net)
Wobbe
Index
(gross)
Heating
Value
(gross)
Gas
Type
Gas
Family Group
Gas
Description
Gas
Designation
Btu/ft
3
(MJ/m
3
)
Btu/ft
3
(MJ/m
3
)
Btu/ft
3
(MJ/m
3
)
Btu/ft
3
(MJ/m
3
)
Density
I
2H,E
Not
Applicable
I
2E+
2H
G20 1226
(45.67)
913
(34.02)
1362
(50.72)
1014
(37.78)
0.555
I
2L
Not
Applicable
Natural
Gas
Second
I
2E+
2L
G25 1004
(37.38)
785
(29.25)
1115
(41.52)
872
(32.49)
0.612
