Operating Instructions
76
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458101ENR7
Function OPL Coin
4 Empty ON ON Always ON
5 Empty ON ON Always ON
6 Buzzer Timer ON ON 5 Sec=Off; Continuous=On
#1 #7 DIP
SWITCH
OFF ON SAFETY
TUMBLE
OFF OFF NO
SAFETY
TUMBLE
ON ON COIN
COUNT
7 Safety Tumble (OPL) or Coin
Count/Pay (Coin)
ON OFF
ON OFF PAY
8 Programming OFF OFF Disable=Off; Enable=On
Table 16 DIP Switch Settings
DIP Switch Functions Explained
1. Tumble dryer Type: This DIP switch selects the type of
tumble dryer, i.e., OPL or Coin.
2. Temperature Units: Selects ºF or ºC for the temperature
display. Factory setting is for ºF.
3. Local/Remote Reversing: Preset at the factory; usually for
local reversing. Remote reversing for use with Reversing
Timer Board only.
4. Empty: Preset at the factory; always ON.
5. Empty: Preset at the factory; always ON.
6. Buzzer Timer: This DIP switch determines the length of
time that the end of cycle buzzer will remain on. “OFF”
indicates that the buzzer will sound for 5 seconds when the
drying cycle is completed. “ON” indicates that the buzzer
will sound continuously until the STOP button is pressed or
the loading door is opened.
7. Safety Tumble (OPL) or Coin count/Pay (Coin): If DIP
switch #1 is set for OPL, then DIP switch #7 in the ON
position enables the safety tumble. If DIP switch #1 is set
for Coin, then DIP switch #7 in the ON position enables
the display of the coin count. DIP switch #7 in the OFF
position enables the display of “PAy”, to indicate that coins
are needed to run the tumble dryer.
8. Programming: This switch enables or disables the
programming feature and should normally be in the OFF
position.
