Testing Machine and Electronic Control Functions
70417701
72
Machine Configuration Display #2 Test
This option shows the machine configuration values
for the machine type.
To start test, control must be in the Testing Mode.
Refer to “How to Enter Testing Feature” at the
beginning of this section.
To enter, press the START (enter) keypad. The display
will show “Cxxx”, with “xxx” the number
corresponding to the machine capacity. Refer to
Table 18.
To exit Machine Configuration Display #2 Test, press
the MED TEMP (<) keypad. The control will return to
the testing mode.
Machine Configuration Display #3 Test
This option shows the machine configuration values
for the machine capacity.
To start test, control must be in the Testing Mode.
Refer to “How to Enter Testing Feature” at the
beginning of this section.
To enter, press the START (enter) keypad. The display
will show “dxxx”, with “xxx” representing the
machine capacity. Refer to Table 19.
To exit Machine Configuration Display #3 Test, press
the MED TEMP (<) keypad. The control will return to
the testing mode.
Value Description
2
25, 30 Pound Tumbler
4
30, 45 Pound Stack Tumbler
5
35 and 55 Pound Tumbler
12
50, 75 Pound Tumbler
Table 18
Value Description
0
Tumbler
17
25 Pound Tumbler
18
30 Pound Tumbler
19
30 Pound Stack Tumbler
20
30 Pound Stack Tumbler – Lower Pocket
21
30 Pound Stack Tumbler – Upper Pocket
22
35 Pound Tumbler
23
45 Pound Stack Tumbler
24
45 Pound Stack Tumbler – Lower Pocket
25
45 Pound Stack Tumbler – Upper Pocket
26
50 Pound Tumbler
27
55 Pound Tumbler
28
75 Pound Tumbler
Table 19
